C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely
C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely
C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely
C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely
C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely
C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely
Specifications
Brand Name :
Cartracker
Model Number :
C003-01-4G
Certification :
ISO9000 CE
Place of Origin :
Shenzhen China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T or western Union or paypal
Supply Ability :
10,000pcs per month
Delivery Time :
1-10 working days after received your payment
Packaging Details :
Packed in carton firstly
Battery :
Built-in 200mAh
Use :
Automotive
Feature :
Real time tracking
GPS accuracy :
10M
DIMENSION :
90mm(L)*40mm(W)*15mm(H)
Voltage Input :
DC9-100V
Chip Module :
MT6261
Weight :
50g
Description

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

Product Specification

Frequency North America EC25-A
EC25-V:LTE FDD: B2/B4/B12
WCDMA: B2/B4/B5
LTE FDD: B4/B13
Nerworks 4G/3G/2G
Battery 200mah
Operating Voltage 9-100v
Location time Hot start≈2s(Open sky)
Location accuracy 5-10M
Operating temperature -20℃～+70℃
Dimension 90*40*15mm
Weight 0.05kg

Feature

FDD LTE 800/850/900/1800/2100/2600MHz
GPS positioning GPS sensitivity: -162dBm
GPS positioning accuracy: 5 meters (under open conditions)
Speed ​​accuracy: 0.1 m/s
Cold start time: <38 seconds
Warm start time: <32 seconds
Hot start time: <2 seconds
Base station positioning Support base station positioning, positioning accuracy: 10~200 meters
Working current Average current ≈22mA (12vDC) maximum current <100mA (12VDC)
Operating temperature -20~+70℃
Material Engineering plastics
Weight 50G
Network 4G LTE/3G WCDMA /2G GSM
Dim. 90*40*15mm
Storage Temp. -40°C to +85°C
Accuracy 5-20m
Operation Temp. -20°C to +55°C
Humidity 20%--80% non-condensing
Working Voltage 9-100V
CPU MTK6261

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

Parameter

Size 90(L)×40(W)×15(H)mm
Working temperature -20℃～+70℃
Working Voltage DC9-100V
Weight 50g
Built-in Battery 200MAH

Hardware Specification

Location Accouracy 10M
GPS Chip MT6261
FDD-LTE Frequency 800/850/900/1800/2100/2600MHz
Hot start≈2s(Open sky)
GPS antenna Built-in,18*18*4 mm
GPRS Class12 TCP/IP

Software Specification

ACC Detection support
GEO-fence support
Cut power support
Vibration support
Movement support

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

components

GPS functions:
protocol: GT06 1)support ACC ignition checking
G-sensor : BS250E 2)support Relay for cutting off power/fuel
input power: 9-100V 3)built-in GPS antenna: 18*18*4 mm
power IC: SL3036H 4)built-in battery, Real time tracking
GSM module: MT6261 5)Geo-fence, over speed alarm,
GPS module: Ublox 6) platform /APP supported

LIGHT Functions
Red LED Connect DC 9-100V power supply and will light continuously.
The red LED is the power signal,
It is always on when the external DC is connected.
blue LED It is he GSM signal indicator.
It is always on when there is no GSM;
It flashes when GSM is normal;
It flashes quickly when transmitting data.
yellow LED It is the GPS signal indicator:
It is always on when there is no positioning;
It flashes after positioning.

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

C003-01-4G Model GPS Tracking Device for Car Truck with Cutting off Power Remotely

Q1: What kind of SIM card do your devices support?
Re: It support global quad band(850/900/1800/1900) SIM card, 2G GSM network, and enable GPRS flow;

Q2: Can i build my own platform, and only use your device?
Re: Yes, of course, you can build your own plaftform, by our offering GPRS protocol, if you want our help to build a independent platform, it will cost technical fee, details you can contact us directly;

Q3: Can i make my own distributor account on your platform?
Re: Yes, you can, if you are a distributor or want to be a distributor, please share all your IMEIs of devices, and then we can
make a distributor account for you, Available to manage your devices.

Q4: Is there phone APP, support Android and IOS system?
Re: yes, you can download the latest app here, www.19gps.net,www.dyegoo.net and it support android and IOS, no Windows OS;

Q5: How about your platform cost?
Re: Free for lifetime;

What is your cell phone number?

My mobile phone number / WhatsApp is +8613717161241. Wechat is 008613717161241
