4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP
4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP
4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP
4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP
4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP
4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP
Specifications
Brand Name :
Cartracker
Model Number :
C003-01-4G
Certification :
CE ISO
Place of Origin :
China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T or western Union or paypal
Supply Ability :
10,000pcs per month
Delivery Time :
1-10 working days after received your payment
Packaging Details :
Packed in carton firstly
Placement :
Portbale
Function :
Real Time Tracking
Size :
90*40*15MM
Weight :
50g
GPRS :
Class12, TCP/IP
Operating current: :
12MA(22VDC)
Frequency :
B1/B3/B8/B34/B38/B40/B41
Description

4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP

C003-01-4G GPS LOCATOR

Product features

1.Precision positioning with accuracy of 5 meters

2.GPS+LBS positioning

3.Functions:

ACC detected

Remote monitoring cut off power/fuel

Overspeed alarm

Geo-fence

etc...

4.Industrial design,workong voltage input range:9-100V

Application

Rental vehicle.credit vehicle,passenger vehicle,taxis,trucks,etc...

4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP

4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP

Device parameter

Equipment parameters:
Electric Speicifications
Power supply mode: Battery power supply
Working voltage range: DC 9V - 100V
Working current: 12mA (24vDC)
Built-in battery capacity: 200mAH

Environmental Features
Working temperature range -20℃ - 70℃
Storage temperature range, low - 30 ℃ -80 ℃
Working humidity range - 20%-80%RH

Communication frequency band
LTE FDD-LTE :B1/B3
　 TDD-LTE :B38/ B39/ B40/ B41
Chip Model MT6261
GSM/EDGE B3/B8
SIM CARD Standard SIM card
Aerial Internal

GPS/LBS Positioning Characteristics
Cold start time - average 34 seconds
Hot start time - average 2 second
Sensitivity (tracking) -162DBM

Shape
Dimension:90mm*40mm*15mm
Houseing Material:Plastic
Weight:50g

4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP

4G LTE Vehicle Wired GPS Tracker Motorcycle Car Alarm Vehicle Tracking Device System with APP

Product Installation Introduction

Equipment built-in GSM antenna and GPS antenna, the installation should ensure a positive upward (toward the sky), and the above non-metal shield block, the proposed installation location:

(1) Below the windshield inside the decorative panel;

(2) Car meter (surface of non-metallic materials) around the shelter;

(3) Rear windshield below the decorative panel;

(4) Inside car door or pillar;

(5) Within the dashboard or under back seat hidden

Description

Material Plastic
Positioning accuracy 5-10m
GPS module MT6261
Frequency Band GSM:850MHz,900MHz,1800MHz,1900MHz
4G:FDD-LTE 800/850/900/1800/2100/2600MHz
GPRS: Class12, TCP/IP
GPS Sensitivity -159dBm
GPS module MTK6261
Platform SMS + APP + computer
Working Voltage 9-100V DC
Backup Battery: Built-in battery 200mAh
GPS positioning time 25s
Working temperature -20℃～+70℃
Storage temperature -40℃～+85℃
Product size 90(L)×40(W)×15(H)mm
Special Functions Vibration alarm, power failure alarm, SOS alarm, movement alarm, fence alarm, overspeed alarm


Contactor Details:

whatsapp: +86-13717161241
mobilephone: +86-13717161241
Wechat:+86-13717161241
website:www.gpstrackerlocator.com
