Specifications
Brand Name :
Cartracker
Model Number :
C003-01-4G
Certification :
CE
Place of Origin :
Guangdong China
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T or western Union or paypal
Supply Ability :
10,000pcs per month
Delivery Time :
1-10 working days after received your payment
Packaging Details :
Packed in carton firstly
Weight :
0.054kg
GPS accuracy :
5M
Band :
FDD-LTE 800/850/900/1800/2100/2600MHz
Network :
4G/3G/2G
Feature :
Power cut off alarm
Work Application :
Web Platform/APP
Type :
4G 3G 2G GPS Tracker
Battery Capacity :
200mAh, standby 50mins to 1hour
Description

4G GPS Tracker For Truck Real-Time Anti-Theft GPS GSM With IOS Android App

Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet.

Vehicle purpose.
Built-in GSM, GPS antenna, compact, elegant appearance.
Support GPS and LBS (Location based service) double tracking solutions.
Support SMS/GPRS/Internet Network data transmission
Support configure the settings remotely
Set multiple functions of security, tracking, monitoring surveillance, emergency alarms and management in its entirety.

Used widely for person, vehicle and other moving objects tracking.

Feature

Remote cut-off (petrol/power) Light and compact
Compel the vehicle to stop by breaking off the fuel connection Small size allowing covert & easy mounting
ACC Igniton Checking GPS + LBS Positioning
Be aware of the ignition status where you need Allow the location to be pinpointed in real time
Tracked by: SMS, APP, Web voltage range:9-100V
Reports location in real time through different interfaces Voltage adaptation up to 100v

Specifications

CPU MTK MT6261
GSM frequency band 850/900/1800/1900MHz
GPS chip MTK6261
GPRS Class12
GPS chip receive sensitivity Tracking sensitivity:-165dBm
capture sensitivity:-148dBm
WIFI location accuracy 10~50M
GPS location accuracy 5~15M
Minimum standby current Less than 0.5 mA
Average standby current Less than 2.5 mA
Average working current <30mA
Working temperature -20~70℃
Working humidity 20% to 80%, noncondensing
MIC Support
Texture Plastic
Size of whole machine 76*26*15 mm
Weight 34g

Notices:
1).GPS tracking can be worked outdoor. Must have mobile phone gsm signal and have GPS signal, It can block GPS satellite signal when there are metal or building above the GPS tracker
2).Pls make sure 4G compatibility 3G WCDMA/2G GSM network sim card, supports making calls, sending messages, GPRS network.have money.

Quick using
1) Open the rubber cover, insert the SIM card to the slot.
2) Put device outdoor ,connect to power supply 9V/36V,
3) Must turn on small switch to“ON" place.
4) Use mobile phone call the device and hang up or sending message “smslink123456" to sim card in tracker ,then send message

4G GPS Tracker For Truck Real-Time Anti-Theft GPS GSM With IOS Android App

FAQ
1:Do you offer the gps tracker protocol so that can use other platform or connect other service?
-Reply: Yes

2:Can i get the mananger account for mananger my all client device?
-Reply: of course ,and you have the authority that register the account for your client

3:How many does one account?
- Repy: no limit the quaility for one account

4:Support the mobile appliction program ?
-Reply: support IOS &Android APK software

1:My company all product warrant 12 months and accept OEM for print your logo or full Neutral has not any logo in cover,can do your local language of user manual
2: All product protocol is free open
