Anti-Theft Mini Gps Tracker For Car With Platform Real Time Tracking No Monthly Fee
This tracker is a new product based on the GSM / GPRS network and GPS satellite positioning system, which set multiple functions of security, positioning, monitoring surveillance, emergency alarms and tracking in its entirety. It can track and monitor remote target by SMS or internet.
Specification
Content | Specs. |
Mainframe Dimension | 76*26*15mm |
Net weight | 34g |
GSM frequencies | 850/900/1800/1900Mhz |
GPS Chipset | UBLOX G7020 |
GPRS | Class12,TCP/IP |
Voltage range | 9-100VDC |
Standby Current | ≤2mAh |
GPS locating time | cold start=38s warm start=32s hot start=2s |
GPS Sensitivity | -159dB |
GPS Accuracy | ≤ 10m |
Work environment temperature | -40℃+80℃ |
Work environment humidity | 20%-80%RH |
Description
Check realtime location via SMS/APP/Platform
BD/GPS/LBS positioning
Built-in battery(180mAh), support external power disconnect alarm for anti-theft
Support Real-time tracking
Remotely stop engine/Oil
Support Overspeed alarm
Support GEO fence alarm
Support Power Off alarm
Support low battery alarm
Suitable for 12V, 36V, 48V, 60V, 72V, voltage range:9-100VDC
SIM Card Installation
The SIM card is not included in the package. Any SIM card that support GSM 2G can work and be available from the user’s local operator.
Note: Before installing the SIM card, please check if the SIM card has PIN code or not. If yes, please use a cell-phone to unlock the card’s PIN code.
1.Product Check. Open the packing box and check the device‘s model and accessories. If the model is wrong or the accessories not complete, please contact the dealer.
2. Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice as reference.
3. SIM card installation. Discharge the cover of the device and uncover the SIM card holder. Then insert the SIM card and cover SIM card holder.
4. Put back the front cover and screw it up.
5. Connect the device to the 9-100Vpower supply.(the red LED constant glow)
6. Install the device in the hidden place of the car;
The SIM card must be with GPRS function and enough deposit. If your SIM card need input PIN when power on, please cancel it.
Anti-Theft Mini Gps Tracker For Car With Platform Real Time Tracking No Monthly Fee
FAQ
Q1. What is your terms of payment?
Normally the payment term is 100% before shipment. For above 10000$, the payment term can be T/T 30% as deposit, and 70% before delivery.
Q2. What is your sample policy?
We can supply the samples if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q3. How about your delivery time?
The specific delivery time is depended on the items and the quantity of your order.
Q4. Can you providing GPS tracking system and APP?
Yes, GPS tracking software/system and APP can be provided, and protocol also can be provided for integrating to your system.
Q5: Does the GPS tracker need a simcard?
It depends on the models. Most of our gps tracking devices need the sim card, please check the network details from the product description before ordering.
