Specifications
Brand Name :
Topshine/Neutral
Model Number :
OGT01
Certification :
ce, FCC, RoHS
Place of Origin :
Guangdong, China
MOQ :
1 sets
Price :
$30.00/Sets-$55.00/Sets
Payment Terms :
PayPal,Western Union,MoneyGram,T/T
Supply Ability :
10000 sets monthly
Delivery Time :
sample within 1-3 days,bulk order within 3-10 days
Packaging Details :
Neutral box (15*16*4.7cm) Unit weight: 0.16Kg
Data Logger :
built-in 2MB
GPRS Internet :
Compatible 2g 3G 4G
GPS Tracking Software :
Web Base/Android/ Ios APP
Acc Detection :
Engine on/off Status
Over Speed :
Over Speed alarm
Warranty :
2 years
Geo Fence :
Geo Fence alarm
Is_Customized :
Yes
Input Voltage (V DC) :
9 ~ 90V
Weight (g) :
40g
Size (mm) :
70*45*25
Description

Universal Car OBD Vehicle GPS Tracker GPS tracking device Diagnostics data with Free GPS Tracking System

OGT01 is a play and plug OBD tracker or Dual SIM OBD tracker which can detect engine on oroff status, also can remote diagnostics vehicle data,then generate OBD report in the tracking platform. Mini size, built-in antennas, easy to be installed and concealed, therefore can satisfy tracking and security demands for vehicles.

2. Applications

Vehicle Real Time Tracking
Vehicle Security/Anti-Hijack
Fleet Management


3. Specification

Items Specifications
Dimension 70*45*25mm
Weight 40g
Input voltage DC +9V~+36V/1.5A
Velocity 515 meters/second (1000 knots) max
Operating Temperature -20°C~75°C
Humidity 5%~95% Non-condensing
Altitude Limit 18,000 meters (60,000 feet) max
LED 2 LED lights to show GPS, GSM status
Cold start 42sec., average
Hot Start 1 sec., average
GSM Frequency Quad Band (GSM 850/900/1800/1900MHz)
GPS Sensitivity -159dB
Positioning Accuracy 10meters, 2D RMS
GPS Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz chip rate
Velocity Accuracy 0.1m/s
Time Accuracy 1 us synchronized to GPS time
Default datum WGS-84
Reacquisition 0.1 sec., average
Flash Memory

2 MB

Function:

* Remote diagnostics vehicle data,for example throttle Open,Engine Speed Averag Fuel,Temperature,Live Load ,Error Code ect data,then generate OBD report in the tracking platform
* Double SIM card tracker can traveling different country consistently
* Detect engine on/ off status
* Inbuilt 2MB data logger for GSM/GPRS blind area
* LBS/GPS Two way locating,still show position
on map when there is no GPS signal
* Integrated devices of diagnose vehicle and GPS tracking
* Integrated internal GPS & GSM antenna
* Waterproof, mini size, easy installation;
* Design for vehicles with OBD port
* Working voltage: 9V DC -24V DC;
* Real Time tracking by SMS/GPRS (Web platform)
* Auto tracking by SMS/GPRS (TCP/UDP supported),track by time or distance interval;
* Tracking via PC platform or Android APP
* Locate by SMS with Google map's link;
* Get actual address name by SMS
* Movement alert which can be used as an alarm;
* Arm/Disarm by SMS or Call
* Geo-fence, over-speed & anti-amber;
* Odometer report function;


Web-based GPS Tracking Platform GPRS01

Android APP GPS tracking platform

Our company advantage :

* Provide 2 free Tracking Platfrom (PC base & Android APP) lifelong. No charge.
* 2 years warranty
* All of our products have CE & RoHS & SGS certification
* Supply OEM&ODM service.
* Our engineer team could customize your personality tracking platform
* Professioal R&D team provide Customization and after-sale service lifelong .
* 100% made of industrial-grade component,GSM module have certified(CE2200)and with legal IMEI code.

Payment & Shipment:

Payment Term: PayPal /western union /TT
Shipping Term: DHL /Fedex /TNT /ARAMEX/EMX
Lead time: Samples within 1 days of delivery.bulk production within 5-7days of delivery.
