Chipset
Intel® C610 Series Chipset
Intel® E5-2600v3 Processor Family
Intel® E5-2600v4 Processor Family

For more information regarding Intel® chipsets, please see the following URL: http://www.intel.com/products/server/chipsets/

On System /Management/ Chipset
HPE iLO (Firmware HPE iLO4 2.0 or later) 4GB NAND
NOTE: 1GB USB user space configurable via UEFI and accessible via
iLO. Read and learn more in the iLO QuickSpecs.

Memory
1.One of the following depending on model Type: HPE SmartMemory DDR4 Registered (RDIMM) or Load Reduced (LRDIMM)
2.DIMM Slots Available 24 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel)
3.Maximum Capacity (LRDIMM) 3TB (24 x 128GB LRDIMM)
4.Maximum Capacity (RDIMM) 768GB (24 x 32GB RDIMM)
5.Maximum Capacity (NVDIMM) 128GB (16 x 8GB NVDIMM)*
NVDIMM support only with the E5-2600v4 processors, and RDIMMs only • 128GB DIMMS cannot be mixed with any other size DIMMs. • *NVDIMMs cannot be used with LRDIMMs. • *A maximum of 16 NVDIMMs can be supported. • NVDIMMs are only supported on factory configured servers with E5-2600 v4 processors, not supported on servers upgraded from E5-2600 v3 to E5-2600 v4 processors.

Storage Controller
1.Entry Models
HPE Dynamic Smart Array B140i Controller
HPE H240ar Smart Host Bus Adapter
2.NOTE: For E5-2600v3 Entry models, the embedded B140i will operate in UEFI mode only. • For legacy mode support an additional controller will be needed. • For CTO orders please also select HPE Legacy FIO Mode Setting (758959-B22). NOTE: The embedded B140i defaults to AHCI off the chipset. HPE Dynamic Smart Array Controller needs to be enabled on the SATA only models if needed.
3.Base Models
HPE Flexible Smart Array P440ar/2GB
4.Performance Models
HPE Flexible Smart Array P440ar/2GB

Internal Storage Devices
1.Optical Drive 8 SFF with optional Universal Media bay Option Kit 764632-B21 VGA, SFF DVD-RW USB Kit Option Kit 818213-B21 VGA, SFF DVD-ROM USB Kit
4 LFF Option Kit 726536-B21 - HPE 9.5mm SATA DVD-ROM Jb Gen9 Kit Option Kit 726537-B21 - HPE 9.5mm SATA DVD-RW Jb Gen9 Kit
2.Hard Drives None ship standard
3.Hard Drive Bays 8 SFF with optional Universal Media Bay or NVMe drive support 4 LFF 10 SFF; 8 SFF Model with optional 2 SFF SAS/SATA kit: 764630-B21

Power Supply
HPE 500W Flex Slot Platinum Hot Plug Power Supply NOTE: Available in 94% efficiency.
HPE 800W Flex Slot Platinum Hot Plug Power Supply NOTE: Also available in 96%. NOTE: Also available in -48VDC and 227VAC/380VDC power inputs 720480-B21 Universal PSU.
HPE 1400W Flex Slot Platinum Plus Hot Plug Power Supply

Security
Power-on password
Keyboard password
QuickLock, Network Server Mode
Serial interface control
Administrator's password
iLO 4 (Integrated Lights-Out 4) has 12 customizable user accounts and SSL encryption
iLO 4 can be disabled via a Global Setting
Integrated Lights-Out can be disabled via a Global Setting
iLO Advanced supports directory services integration
TPM 2.0
UEFI

ACPI 2.0b Compliant
PCIe 3.0 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
USB 3.0 Support
Energy Star ASHRAE A3/A4 NOTE: The DL360 Gen9 is now one of the first HPE ProLiant Gen9 Servers with Extended Ambient Support up to 45C for data center infrastructures designed for better energy efficiency.

1U Rack form factor
8 SFF Drive Bay Version and 10 SFF Drive Bay Version: 1.7" (4.32cm) Height x 17.11" (43.47cm) Width x 27.5" (69.85cm) Length
4 LFF Drive Bay Version: 1.7" (4.32cm) Height x 17.11" (43.47cm) Width x 29.5" (74.67cm) Length
