Chipset:
1.Intel® C610 Series Chipset
2.Intel® Xeon® E5-4600v4 Processor Family
3.Intel® Xeon® E5-4600v3 Processor Family

On System Management Chipset:
HPE iLO 4 (4GB NAND) NOTE: Read and learn more in the iLO QuickSpecs.

Memory:
Type:1.HPE SmartMemory
2.DDR4 Registered (RDIMM) or Load Reduced (LRDIMM)
3.DIMM Slots Available 48 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel)
4.Maximum Capacity (LRDIMM) 6TB 48 x 128GB LRDIMM @2400MHz
5.Maximum Capacity (RDIMM) 1.5TB (48 x 32GB RDIMM @2400 MHz)

Internal Storage Devices:
1.Hard Drives None ship standard
2.Hard Drive Bays 8 hot plug SFF SAS/SATA HDD Bays in Entry and Base Models 16 hot plug SFF SAS/SATA HDD Bays in Performance Models

Network Controller:


Expansion Slots:

Storage Controller:


Power Supply:
1.HPE 1200W Common Slot Platinum Hot Plug Power Supply
2.2 HPE 1200W Common Slot Platinum Plus Hot Plug Power Supplies

Common Slot Power Supplies:
One of the following depending on power requirements:
HPE 1500W Common Slot Platinum Plus Hot Plug Power Supply
HPE 1500W Common Slot 48VDC Hot Plug Power Supply
NOTE: 1500W power supply supports high line voltage only.
HPE 1200W Common Slot Platinum Plus Hot Plug Power Supply
HPE 1200W Common Slot Platinum Hot Plug Power Supply Prior to making a power supply selection it is highly recommended that the HPE Power Advisor is run to determine the right size power supply for your server configuration. The HPE Power Advisor is located at: http://www.hpe.com/info/hppoweradvisor. Hewlett Packard Enterprise Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of ProLiant and Integrity servers, as well as HPE Storage solutions, and are designed to provide the highest power supply efficiency without degrading system performance. HPE CS power

Serial 1 rear
Video 1 front (optional with Universal Media Bay kit); 1 rear
iLO 4 Remote Management 1
Micro SD Dual Slot 1
NOTE: Requires the optional HP Dual Micro SD 8GB USB kit.
USB 2.0 Ports 5 total: 2 front (optional); 2 rear; 1 internal
USB 3.0 Ports 4 total: 1 front; 2 rear, 1 internal

Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
VMware
