5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer
5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer
5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer
5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer
Specifications
Brand Name :
ChenYu Technology
Model Number :
5HCY-30
Certification :
ISO9001, ISO14001, CE
Place of Origin :
Lu'An, China
MOQ :
1 Set
Supply Ability :
100 Sets per Month
Delivery Time :
30 Working Days
Packaging Details :
Wooden Case
Type :
Maize Drying Equipment
Use :
Maize Drying
Loading capacity :
30000 KG
Net weight :
8000 KG
After-sales Service Provided :
Engineers available to service machinery overseas
Applicable Industries :
Food & Beverage Factory, Farms, Food Shop, Food & Beverage Shops
Description

5HCY-30 Maize Dryer Machine 17.35kw With On Line Moisture Meter Automatical System

Product Description:

1, Using mix type drying method with angle pipe , hot exchange and evaporative way of drying to make sure the drying is evenly and fully;

2, Prevent drying crack broken rice we adopt constant drying speed control, water reduction rate and air temperature controlled by computer, without manual settings;

3, Prevent grain spoiled, machine running under proper temperature ;

4, Prevent excessive drying adopting automatic, accurate and safe water monitoring devices, it can be shut down automatic;

5, Body of tower is low and compact, easy to be installed;

6, High moisture rice and wheat quality also can be dried, widely used for rice, wheat, corn, soybeans and other crops;

7, Safe, reliable, easy to be cleaned;

8, A variety of fuels available, economic, environmentally friendly;

9, Easy to maintain, convenient to use;

10, Excellent quality raw materials for drying tower body, more durable.

Parameters:

Model 5HCY-30
Structure Batch type circulating
Drying way Indirect heating
Cyclic batch (t) 30

Loading capacity		 paddy(kg)(apacity＝560kg/m3) 12000-30000
wheat(kg)(capacity＝700kg/m3) 16000-30000
Total weight(kg) 8000
diemension(Largest)
(L×W×H)mm		 4756*5529*11959

Ventilation fan		 Model 4-72-6A
rated air flow (m3/h) 9070-15177/ and Two set
Burner(Optional) Model husk burner/gas burner/Diesel burner
Ignition Manual
fuel rice hull,firewood,straw,anthracite
electricity Voltage/frequence three phase 380V single phase 220V/50hz
kW motor power 17.35
function
loading time		 paddy(min) 55-65
wheat(min) 55-60

unloading time		 paddy(min) 55-65
wheat(min) 55-60
drying rate (%/h) 0.5-1.2
device safety device Grain temperature sensor, Fault alarm, Full load buzzer,Over0temperature alarm, Thermal-over relay, Hot air temperature sensor, Overload protection device, Leakage protection device
standard device Online moisture monitor, Conveying system, Unloading system, Drying system, Tempering system, Elevator, Exhaust fan in low noise, Automatic control system

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

Our quality control

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

Our customer case

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer

5HCY-30 Maize Dryer Machine 30000 KG Batch Type Circulating Paddy Dryer
