Horizontal Mini Paddy Dryer Machine 12000kg Loading Capacity CE Approved
Horizontal Mini Paddy Dryer Machine 12000kg Loading Capacity CE Approved
Specifications
Brand Name :
ChenYu Technology
Model Number :
5HCY-15H
Certification :
ISO9001, ISO14001, CE
Place of Origin :
LU'AN CHINA
MOQ :
1 Set
Price :
USD 16500-19500
Supply Ability :
100set /30days
Delivery Time :
30 working days or To be negotiated
Packaging Details :
High-grade wooden case with reinforcing rib and vane or follow customer request
Type :
Paddy Drying Machine
Use :
Rice Paddy Drying
After-sales Service Provided :
Engineers available to service machinery overseas
Applicable Industries :
Food & Beverage Factory, Farms, Food Shop, Food & Beverage Shops
Description

15 Tons per Batch Cross Flow Type Paddy Dryer machine

Product Main Characteristics:

1, Using horizontal multi-slot dryer section, grain crisscrossed loop cycle, hot exchange and evaporative way of drying to make sure the drying is evenly and fully;

2, Prevent drying crack broken rice, we adopt constant drying speed control, drying rate and air temperature controlled by computer, without manual settings;

3, Prevent mildew of the grain, machine running under proper temperature ;

4, Prevent excessive drying adopting automatic, accurate and safe water monitoring devices, it can be shut down automatic;

5, Body of tower is low and compact, easy to be installed;

6, High moisture rice and wheat also can be dried, widely used for Corn, Wheat, Sesame, Rapeseed, Peanut, Melon seeds, Cotton seeds, Soybean, Mung bean and so on;

7, Safe, reliable, easy to be cleaned;

8, A variety of fuels available, economic, environmentally friendly;

9, Easy to maintain, convenient to use;

10, Excellent quality raw materials for drying tower body, more durable.

Parameters:

Model (Cross type ) 5H-12
(12T/batch)
Structure Batch type circulating
Drying way Indirect heating
Cyclic batch 12

Loading capacity		 paddy(kg) 2300-12000
wheat(kg) 2700-12000
Total weight(kg) 2800
Diemension Body
(L×W×H)mm		 2106×2080×7910
Diemension
(L×W×H)mm		 4314×2979×9030

Ventilation fan		 Model 4-72-6A
rated air flow(m3/h) 6677-13353
Burner
( Optional)		 Model husk burner/gas burner/Diesel burner
Ignition manual
electricity Voltage/frequence three phase 380V single phase 220V/50hz
kW motor power 7.87
function
loading time		 paddy(min) 55-65
wheat(min) 50-60

unloading time		 paddy(min) 55-65
wheat(min) 50-60
drying rate (%/h) 0.5-1.2%
device safety device Full load buzzer,Thermal-over relay,Temperature Control Instrument, Hot air temperature sensor, Overload protection device, Leakage protection device
standard device Online moisture monitor, Conveying system, Unloading system, Drying system, Tempering system, Elevator, Exhaust fan in low noise, Automatic control system
