Black Graphite Hardened Steel Bushings 40*50*50 High Compression Resistance
Black Graphite Hardened Steel Bushings 40*50*50 High Compression Resistance
Black Graphite Hardened Steel Bushings 40*50*50 High Compression Resistance
Black Graphite Hardened Steel Bushings 40*50*50 High Compression Resistance
Specifications
Brand Name :
IFAGb
Model Number :
40*50*50
Certification :
China
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiation
Payment Terms :
T/T, L/C, PayPal
Supply Ability :
1000 Piece/Pieces per Week
Delivery Time :
15-30days
Packaging Details :
Standard Packing
Material :
hardened bearing steel
product name :
graphite steel bushing
Base material :
GCr15
Bearing capacity :
250N/mm2
Basic hardness :
HB58~60
Friction coefficient μ :
<0.17
Use PV value :
2.5N/mm2*m/s
type :
Steel Bushing Sleeve
Description

graphite steel bushing,40*50*50,60*75*60,hardened bearing steel, grey black,etc.

Material: Hardened Bearing Steel
Base Material: GCr15
Basic Hardness: HB58~60
Use PV Value: 2.5N/mm2*m/s
Product Name: Graphite Steel Bushing
Bearing Capacity: 250N/mm2
Friction Coefficient μ: <0.17
Type: Steel Bushing Sleeve

product description:

Graphite steel bushingis a reinforced product with high compression resistance. It can discharge lubricating particles during operation and create a layer of diaphragm between the shaft and the sleeve, which is more resistant to bite than single oil lubrication. The advantages are particularly adapted to the support of the hoisting machinery.

Recommended use:

For example: roll machine support, crane support, but not suitable for use in water or acid and alkali.

Technical Parameters:

Base material: GCr15

Bearing capacity: 250N/mm2

Basic hardness: HB58~60

Friction coefficient μ: <0.17

Higher sliding speed: 0.1m/s

Higher use temperature: 350 ° C

Use PV value: 2.5N/mm2*m/s

graphite steel bushing,40*50*50,60*75*60,hardened bearing steel, grey black,etc.

Material: Hardened Bearing Steel
Product Name: Graphite Steel Bushing
Bearing Capacity: 250N/mm2
Application: Roll Machine Support
Color: Grey Black
Base Material: GCr15
Basic Hardness: HB58~60
Use PV Value: 2.5N/mm2*m/s
