Specifications
Brand Name :
GRAT
Model Number :
EA-20
Certification :
IP67,CCC, ISO, CE,CNAS,SIL
Place of Origin :
Wuhan, Hubei, China
MOQ :
1 pc
Price :
USD $80.00/ Piece
Payment Terms :
LC, T/T, D/P, PayPal, Western Union
Supply Ability :
1000PCS/Week
Delivery Time :
3 working days
Packaging Details :
Carton/Wooden Box
Type :
Regulating
Power Supply :
AC220V/DC24V
Ambient Temp :
-30ºC--60ºC
Application :
Food, Environmental Protection, Paper-making, Chemical Engineering, and Power
Action Time :
15S - 25S
Communication Protocol :
Modbus
Torque :
20NM
Size :
DN25 ( up to DN25 )
Adjustable Range :
30% - 100%
Speed Regulation Mode :
PWM
Position Display :
OLED
Modulation accuracy :
0.5%
Description

20NM Miniature Size Precise control Iot Electric Actuator with Multiple feedback methods​


Product Description:

20NM Miniature Size Iot Electric Actuator /IP67/Fixed Ball Valve

Description:

EA-20 Compact Electric Actuator is the latest ultra-small electric actuator developed by our company. It is used

for valves with angular stroke operation such as butterfly valves, ball valves, and damper valves to control

the opening, closing or adjusting the valve opening. It is suitable for automation systems across various

sectors including food, environmental, paper, chemical, and power industries.

Features:

* Low power consumption and high efficiency: It only requires 10W of power, saving energy costs and being able to

work efficiently and stably at the same time.

* Smooth speed regulation: Adopting PWM stepless speed regulation ensures a stable operation process of the actuator

and provides more stable control.

* High-performance motor: The built-in brushless motor with overload protection is stable, reliable and has a long service life.

* Real-time parameter display: The OLED real-time displays status and parameter information in Chinese or English,

providing more real-time feedback and fault alarm information during the use process.

* Precise control: The adjustable range is wide, from 30% to 100%, and it has a control accuracy of 0.5%, precisely meeting

the control requirements of different occasions.

* Multiple feedback methods: It supports feedback methods of 4-20mA/0-10V/1-5V, ensuring the accuracy of control.

Specification:

Power supply AC 220V / DC24V

Torque

 20NM

Valve Size

 DN25 ( up to DN25 )

Speed Control Method

 PWM

Adjustable Range

 30%-100%

Control signal

 4-20MA/ 0-10V/1-5V

Communication Protocol

 Modbus Compatible

Action time

 15s-25s

Gyration angle

 0-90°

Position Display

 OLED Real-time Display

Manual Function

 Hexagonal Wrench
Output Shaft Inner Concave Octagonal (11x11)

Protection level

 IP67

Modulation accuracy

 0.5%

Ambient Temp

 -30ºC--60ºC

Installation size drawing

Precise Control Iot Mini Electric Actuator 20NM With Multiple Feedback Methods

Precise Control Iot Mini Electric Actuator 20NM With Multiple Feedback MethodsPrecise Control Iot Mini Electric Actuator 20NM With Multiple Feedback Methods

Control Diagram

Precise Control Iot Mini Electric Actuator 20NM With Multiple Feedback Methods

Packing & Shipping:
1.Packing: inner with bubble wrap,outer with cardboard box and wooden case.
2.Transportation:by sea, by air,by train.
If you have other requirements, please feel free to tell us.
