Stable CNC Universal Grinder, Full Automatic Industrial Cylindrical Grinding Machine FX27-60CNC

Technical specification:

New design concept,low cost and simple operation:

Frame structure, using high-grade cast iron (FC30), low center of gravity design, the latest finite element computer aided analysis, the rigidity

design is more than 108N/m, the lowest natural frequency design is more than 150HZ. This the excellent structure design makes the machine fully

shockproof and shock-absorbing, ensuring its high rigidity and maximum damping performance, thus prolonging the service life of the machine.

Bed displacement and feeding mode:


1.The left and right displacement of the table and the feeding of the grinding wheel head are all done by hand Dynamic operation.

2.The bed displacement is driven by oil pressure, and the grinding wheel head feed is manually operated.

3.The bed is driven by oil pressure, the grinding wheel head is sent and returned longitudinally, and the feed is operated manually.

4.The bed displacement is driven by oil pressure, the grinding wheel head longitudinal fast feed and fast return, automatic feed operation.

5.Add automatic measuring device.


Device description:

1. The body and components are cast by Milhanna high grade cast iron FC30, which is artificially normalized heat treatment and then treated by natural aging. Components are processed by YASDA, MITSUI SEIKI, TOSHIBA, ELB and other world-class equipment once clamping processing. Precision size can be up to micron level, to ensure high precision equipment basic components.


2. Machine guide rails and precision ball screws are continuously lubricated by automatic lubrication system to ensure longer service life and accuracy. The cooling system is separated from the body to eliminate vibration and favorable heat dissipation.

3.Equipped with Siemens 828D CNC automatic grinding system, and secondary development, man-machine dialogue fool operation, with many optional equipment to choose from, including inner hole grinding device, automatic end measuring device, automatic outside diameter measuring device, etc.

4. The grinding feed system is composed of a V and a flat track of hand-crafted precision shovel, with automatic lubrication system and C3 level precision grinding ball screw, which can achieve smooth movement, excellent repeated positioning accuracy and long track life.

5. The standard configuration of the grinding wheel spindle is rear four and rear two bearing structure. High precision dynamic and static pressure spindle can also be selected, which has the characteristics of high rotation precision, high dynamic stiffness, good vibration resistance, high grinding efficiency and good grinding surface quality. For special work-piece grinding, the grinding wheel speed can be adjusted, up to 3500 RPM and 60m/s.

6. The tail seat is designed to be both rigid and robust. A hardened alloy steel sliding cylinder encrusted in the cast iron body is designed to carry the MT4 top core. The jacking force of the sliding cylinder can be easily changed by adjustment knobs at the rear. Special accessories oil pressure tail seat with a pedal to facilitate unloading work parts.

7.Siemens numerical control system as the standard configuration, after secondary development, all Chinese operation interface, easy to use. Equipped with Siemens high performance servo motor, the equipment CNC system and drive system have better compatibility, at the same time with automatic sand repair and automatic compensation function, to ensure the stability and precision of feed and grinding.
