Specifications
Brand Name :
ZW
Model Number :
forged ball,grinding media ball
Certification :
ISO9001:2008
Place of Origin :
Jinan city,Shandong province,China
MOQ :
1 tons
Price :
Negotiable
Supply Ability :
Annual output 80000 tons
Delivery Time :
3 days after order confirmation
Packaging Details :
container bags ,steel drum
Service :
One-stop Service
Impact Test :
≥13AK.j/cm^2
Heat Treatment :
water quenching
Hs Code :
73261100
Place Of Production :
Shandong, China
Useage :
grinding media
Package :
Bags or Steel Drum
Breakage Rate :
Less than 0.5%
Application :
Cement plants, mines, power stations, chemical industries, etc.
Description

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Product

‌Grinding steel balls‌ are a main tool for grinding materials, usually used in ball mills. Grinding steel balls produce abrasive effects through collision and friction with materials, thereby achieving the grinding effect of materials

Types and uses
‌Forged steel balls‌: Made by forging, spinning, rolling, etc., with high strength and wear resistance, widely used in industry and mining fields‌
‌Cast steel balls‌: Produced by casting process, including high chromium steel balls, medium chromium steel balls, low chromium steel balls, etc., suitable for cement, thermal power generation, metallurgy and mining industries‌

Forged Ball Details:

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Material Chemical Elements
C Si Mn P/S Cr Hardness (HRC)
45# 0.42-0.50 0.17-0.37 0.5-0.8 <0.035 <0.25 60-65
60MN 0.55-0.65 0.17-0.37 0.7-1.0 <0.04 <0.25 58-63
B2 0.72-0.85 0.17-0.37 0.7-1.0 <0.04 0.4-0.6 55-58
B3 0.58-0.66 1.3-1.9 0.65-0.8 <0.025 0.7-0.9
 56-65
B6 0.97-1.03 0.2-0.3 1.0-1.1 <0.025 0.5-0.6 61-65

Material

25mm-50mm

HRC

60mm-90mm

HRC

100mm-125mm

HRC

130-150mm

HRC
Surface Core Surface Core Surface Core Surface Core
C45 55-58 55-58 50-68 23-30 48-52 22-26 48-52 22-25
60Mn 58-62 55-60 58-62 30-36 57-61 26-32 57-61 26-30
B2 60-64 58-64 57-64 45-60 55-60 38-48 55-60 38-42
B3 62-65 60-65 60-65 58-65 56-65 50-62 56-63 50-55
B6 62-65 60-65 61-65 58-65 60-63 50-62 61-63 50-55

Casting Ball

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Production Line

1) Traditional Forged

Raw material →Cutting →Heating → Water quenching → Tempering

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

2) Auto Hot Rolling

Raw material →Hot Rolling Mill → Water Quenching → Tempering

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

3) Casting
Raw material preparation →Smelting→ Pouring→Cooling and demoulding→Heat treatment and inspection

Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Test
Packing & Shipping
Steel drum (800-950kg per drum)
Container Bag (1000kg per bag)
Two drums with Pallet
Mill Steel Ball Grinding Medium Wear Resistant Stone Grinding Media Forged Steel Balls

Company Profile
Jinan Zhongwei established in 2000 , we are a leading manufacturer and professional exporter grinding balls in China.
Our company covers an area of 15000 square meters, now we have 150 staff, including 13 technical staff. Annual output is 50000 tons to 80000 tons .

Main products : forged steel ball, cast iron ball ,grinding rod, cylpebs
We have exported to 20 more countries, UAE, Zambia,South Africa, Peru, Chile, Australia, UK, USA, Turkey and so on.

Question and Answer

Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.

Q2. Do you have any MOQ limit for the order?
A: 1ton MOQ.

Q3. How to proceed an order ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
