Main features:

* Imported bipolar heat insulation block, good heat insulation effect will not appear fracture and parallel bending phenomenon.

* The machine has a pressure detector, when the pressure, vacuum and temperature do not reach the set value, the equipment will not run automatically, to ensure the consistency of the cell packaging effect.

* The pressure of the upper and lower heads can be adjusted by the pressure regulator to achieve different process parameters.

* The upper and lower head is driven by the cylinder through two linear guide sleeves, and the upper and lower movement is flexible, and the guide is accurate to ensure the parallelism of the product after the edge sealing.

* Can be applied to different specifications of product batteries, and the adjustment is simple and convenient.

* The mechanism or parts in contact with the electrolyte are treated with anti-corrosion to ensure long-term and stable operation of the equipment.

* The frame is assembled with profiles and sealing plates, and the equipment is exquisite, small and beautiful.

Technical parameters:

* The cavity is made of aluminum alloy, corrosion resistance, solid structure;

* Vacuum: ≤-96Kpa (buyer's own vacuum pump);

* Head temperature: room temperature ~ 250℃, temperature adjustable;

* Temperature control accuracy: ±1.5℃;

* Heat seal pressure: 0 ~ 7Kg/cm² adjustable;

* Heat sealing time: 0 ~ 99 seconds adjustable;

* Edge width: 5±0.4mm (according to customer requirements);

* Maximum edge size: 200mm;

* Max battery range length 200, width 120mm;

* Seal thickness range: 60~300um;

* Sealing thickness accuracy (mm) : any two point package thickness difference <15um;

* Gas consumption: about 0.2L compressed gas/once per seal;

* Air pressure working speed: ≥180 times /h;

* Power: 300W heating tube, heating power consumption of about 0.6KW;

* Power supply: 220V/50Hz;

* Air source: 0.5 ~ 0.7Mpa;

* Dimensions: 650 * 550 * 1450mm;

* Weight: about 300Kg.

Equipment composition:

This machine consists of the following parts:

Mechanical part:

1. Pumping and unloading vacuum device: 2 sets of vacuum cylinder valve, 1 set of vacuum pumping and vacuum draining;

2. Upper and lower heat head components: heat insulation block, head, heating block, base, head guide block;

3. Upper vacuum chamber components;

4. Lower vacuum chamber components;

5. Bayonet mechanism;

6. Upper cavity cover plate lifting mechanism;

7. External racks, doors, Windows, and protective panels.

Electrical and standard parts:

1. Control PLC: display control;

2. Man-machine interface: display and control;

3. Temperature controller: display control;

4. Vacuum meter: Panasonic;

5. Cylinder and pneumatic components: Airtac.
