LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
Specifications
Brand Name :
G-Tech
Model Number :
V-
Certification :
CE ROHS
Place of Origin :
Guangdong China
MOQ :
500pcs
Payment Terms :
L/C, T/T
Supply Ability :
10000pcs
Delivery Time :
7-25workdays
Packaging Details :
Carton packing
Price :
Negotiation
Product name :
10kva online ups prices
Type :
online
Weight :
Customized
Protection :
Overvoltage
Certificate :
CE
Phase :
Single Phase
Color :
Black
Description

High Frequency Online UPS 1KVA with LCD display


Specification

Model PT-1K PK-1KL PT-2K PT-2KL PT-3K PT-3KL
Capacity 1000VA/9000W 2000VA/1800W 3000VA/2700W
INPUT
Voltage range Full load:160Vac ±5%-300Vac±5%; no-load:110Vac±-300Vac±5%
Power factor 0.9
Frequency range 40Hz-70Hz
Phase Single phase with ground
OUTPUT
Output voltage 220Vac
AC Voltage regulation ±1% (Batt.Mode)
Frequency range 47-53Hz of 57-63Hz(Synchronized range)
Frequency range 50±0.25Hz or 60±0.3Hz(Batt.mode
Overload

＞100%＜110%:warning

＞110%＜130%:UPS shuts down after 1 minute in battery mode,or transfer to by pass when the utility is normal

＞130%:UPS shuts down immediately in battery mode,or transfer to bypass when the utility is normal.
Current crest ratio 3:1
Harmonic distortion ≤6% THD(non-linear load)
Transfer time AC Mode to Batt Mode:0ms; Inverter to Bypass:4ms(Typical)
Wave form(Batt.Mode) Pure Sinewave
EFFICIENCY
AC Mode ≥85% ≥88%
Battery Mode ≥83% ≥85%
Battery

Battery type

(standard Mode)

 12V/7-9AH
Quantity 2pcs 6pcs 6pcs 8pcs
Recharging time 4 hours recover to 90% capacity(Typical)
Charging current Standard Model :1A(max)
Charging voltage 27.3V±2%/41.0V±2% 55.2V±2%/82.1V±2% 82.1V±2%/109.4V±2%
PHYSICAL
Dimension(mm) 350*145*230 410*190*325
Net weight(kg) 18.6 9.0 19.0 10.0 25.0 11.0
ENVIRONMENT
Operation humidity 20-95%RH@0-40℃(non-condensing)
Noise level ≤40dB(1m)
MANAGEMENT
Smart RS232 or USB Rs232(default) USB(optional)
Optional SNMP Power management from SNMP manager and web browser

LCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage ProtectionLCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage ProtectionLCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage ProtectionLCD Display G Tech UPS High Frequency Online 1KVA Single Phase Overvoltage Protection
FAQ:
Q1. MOQ & Samples.
A: MOQ is 1 pcs. Welcome sample order to test and check quality. Customized is available.

Q2. What about the lead time?
A: Samples within 1-5 days, big order within 2-3 weeks.

Q3. How do you ship the goods?
A: By express, air cargo and sea. We have MSDS, test report for safe transport as non-danger-ous products.

Q4. Is it OK to print my logo on product?
A: Yes. Free logo print.

Q5:Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.

Q6:How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.01%. Secondly, during the warranty period, we will repair or replace defected products. 24 hours alling support!

Q7:If we could accept OEM & ODM Service?
Accept customized, such as the brand, Logo, Container color etc.
