20.48KWh Stackable Home Battery All-in-one Home Energy Storage LiFePO4 Battery Pack
20.48KWh Stackable Home Battery All-in-one Home Energy Storage LiFePO4 Battery Pack
Specifications
Brand Name :
Gtech
Model Number :
LS-20
Certification :
CE/ROHS
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
300 PCS per day
Delivery Time :
Sample: 7 days; Qty order: 20 days
Packaging Details :
Standard Export Battery Package
Description

20.48KWh All-in-one Stackable Home ESS

Description:

Gtech 20.48KWh home ESS is a fantastic all-in-one type of battery system that's becoming increasingly popular. With its stackable design and powerful energy capacity, it's the perfect solution for anyone who wants to take control of their home energy usage.

Features:

All-in-one stackable ESS

5KW pure sine wave power output

High safe standard 3U top LFP battery module

4 PCS 51.2V100Ah batteries in one cluster

Long service life more than 5000 cycles

Charging current from 20A~100A configurable

Smart BMS ensuring each cells balance and all protections

Max support 16 battery modules cascade connection(4 stacks)

CAN/RS485/RS232/Dry contact multi-communication interface

Compatible with main inverter brands in the market

Integrated DC switch to enhance safe and no-worry operation

Widely used for home, community and office energy storage

Bottom moveable wheels easily for portable purpose

Specifications:

Battery energy 20.48kwh
Battery module 51.2V-100
Number of battery modules 4
Battery Type Lithium Iron Phosphate
Rated voltage 51.2V
Battery voltage range 40V~58.4V
Battery capacity 100Ah
Maximum continuous charging current 100A
Maximum continuous discharge current 100A
Net weight 52kg
Overall dimensions (L*W*H)mm 550*572*191
Range of working temperature Charging: 0~45℃ Discharging -20~50℃
Cycles Room temperature @ 0.5C, 5000 charge and discharge cycles, SOC≥80% initial capacity
Communication method CAN/RS485/RS232
Inverter (optional)

AC output

 Output rated power 5000W
Output waveform pure sine wave
The output voltage 208/220/230/240Vac±5%
Output frequency 50Hz ~ 60Hz
Peak efficiency (battery mode) >94%
Overload capacity

60S@102%~110% load; 10S@110%~130% load;

3S@130%~150% load; 200ms@≥150% load;
Solar charging@AC charging PV maximum open circuit voltage 450V/DC
Photovoltaic array MPPT tracking voltage 120~430V/DC
Photovoltaic maximum charging current 60~80A
AC maximum charging current 60~80A
Mains charging voltage range 90~280VAC (APP mode); 170~280VAC (UPS mode)
Charging mode Two-stage/three-stage charging mode,/lithium battery
Total charging current of mains and controller 80A
net weight 13kg
Inverter dimensions (L*W*H) mm 550*572*191

Applications:

20.48KWh Stackable Home Battery All-in-one Home Energy Storage LiFePO4 Battery Pack
