Automotive Ambient Lighting Solution Body Systems OEM ODM Board PCB Assembly
Automotive Ambient Lighting Solution Body Systems OEM ODM Board PCB Assembly
Specifications
Conformance to AEC-Q100 Grade1 standard :
The main chip (BAT32A237) meets automotive quality standards
High-precision PWM control :
Directly controls RGB three-color lights for precise color control
Auto-addressing function :
Implemented through sampling circuit and software, simplifying the structure
Automatic address assignment :
Assigns addresses based on the node's location
Simplified storage and installation process :
Improves universality and ease of installation
Ambient mode :
Allows for precise color and brightness adjustment in ambient lighting
Description

Automotive Ambient Lighting Solution

Description

The ambient automotive lighting Solution is designed based on the BAT32A237 chip of Arm Cortex ® M0+ core. LIN bus is used to communicate with the host, supporting sleep and wake-up, reducing the power consumption of the system.Through the pull-up and constant current switch control, combined with the current sampling circuit, the LIN auto-addressing function is implementation.

Performance characteristics of automotive ambient lighting Solution:

> The main chip of BAT32A237 Conforms to AEC-Q100 Grade1 standard

> The function of auto-addressing is realized by sampling circuit and software, and the structure is simple

> RGB three-color lights are directly controlled by high-precision PWM

> Ambient mode is available, precise color and brightness adjustment

> it can automatically assign the address according to the node location

> Simplify storage and installation process, improve the Universality

Attribute Attribute Value
Conformance to AEC-Q100 Grade1 standard The main chip (BAT32A237) meets automotive quality standards
Auto-addressing function Implemented through sampling circuit and software, simplifying the structure
High-precision PWM control Directly controls RGB three-color lights for precise color control
Ambient mode Allows for precise color and brightness adjustment in ambient lighting
Automatic address assignment Assigns addresses based on the node's location
Simplified storage and installation process Improves universality and ease of installation

System diagram

Automotive Ambient Lighting Solution Body Systems OEM ODM Board PCB Assembly
