Industry

Items to clean

Molds

Plastic tool models

Electronics

Relay—remove metal filings and impurities,

Potentiometer-- impurities and oil stain on moving contact,

Vacuum tube parts-- Dirt and impurity on the polar plate of the electron gun,

Semiconductor element--Dir on the surface of the silicon wafer and crystal wafer,

Capacitor--Dirt on pins of the capacitor,

Printed circuit board--Ink and oxide left during processing printed circuit board,

Magnetic head--Dirt on the surface of the magnetic head.

Mechanical

Bearing, gear--Metal filings and impurities left during the processing of internal and external sheath of bearing,

Spring--cleaning before spring turning black,

Vernier caliper, measuring tool--Metal filings and oil stain left during the processing of parts,

Oil choke, oil pump--Metal filings and dirt left during the process of the inner hole of oil choke and oil pump,

Screw rod, air valve, pneumatic elements--Iron filings, cutting oil and

abrasive left while processing.

Automotive, motorcycle, aircraft

To remove oil, grease, preservative, plastic residue left during mechanical cutting, grinding abrasive, glass fiber, dust, graphite, and tar from Automotive air valve, glow plug, gasification plug, fuel pump, piston ring, battery terminal, machine control hand-wheel,

motorcycle air-valve,etc.

Armurerie

weapons cleaning, such as guns, rifle, bullets, handcuffs, etc.

--For cleaning and lubrication.

Printing industry

Rotative machine, metal plate, Printer ink head, printer cartridges

-- To clean ink, oil, and dye on the surface of printing machine & parts.

Repair industry

Musical instrument repair shop, vehicle maintenance shops, motorcycle repair shop, mobile phones & interphone repair shop, gun repair shop, etc.

--To clean dirt, impurity, and oils from surface of tools and spare parts.

Model

Tank Size

LxWxH(mm)

Unit Size

LxWxH(mm)

Volume

(L)

Ultrasonic Power

(W)

Ultrasonic Frequency

(KHz)

Heating Power

(W)

Timer

(min)

Temp.

(°C)

ST53A/B

500*350*300

645*496*615

53

900

28/40kHz

2000

0-60

minutes

/untimed

30-110(℃)

ST77A/B

550*400*350

687*540*610

77

1200

3000

ST105A/B

600*500*350

745*645*665

105

1500

4000

ST144A/B

600*600*400

745*745*715

144

1800

5000

ST189A/B

700*600*450

845*745*765

189

2400

6000

ST288A/B

800*600*600

942*745*915

288

3000

7000
