Specifications
Brand Name :
Daway
Model Number :
15-5PH, EN 1.4545, DIN X5CrNiCu15-5
Place of Origin :
China
Certification :
SGS
MOQ :
1 ton
Payment Terms :
T/T, L/C
Supply Ability :
500 tons per month
Delivery Time :
15 days after receipt 30% of value
Packaging Details :
seaworthy
Price :
negotiable
Material :
15-5PH, EN 1.4545, DIN X5CrNiCu15-5
Product :
15-5PH stainless steel bars
Dia :
3.0~450mm
Surface :
black, peeled, polished, ground
Description
15-5PH, EN 1.4545, DIN X5CrNiCu15-5 stainless steel round bars

15-5PH is a variant of the older 17-4PH chromium-nickel-copper precipitation hardening stainless steel.

Both alloys exhibit high strength and moderate corrosion resistance.

High strength is maintained to approximately 600 degrees F.

The 15-5PH alloy was designed to have greater toughness than 17-4PH.

This improved toughness is achieved by reduced delta ferrite content and control of inclusion size and shape.

Applications:

  • Aircraft components
  • High pressure corrosive fabricated parts such as valves
  • Shafts
  • Fasteners
  • Fittings and gears

Chemical composition ( weight % )

Grade C Si Mn P S Cr Ni Cu Nb
15-5PH 0.07 max 1.00 max 1.00 max 0.040 max 0.030 max 14.0~15.5 3.5~5.5 2.5~4.5 0.15~0.45

A H900 H925 H1025 H1075 H1150 H1150-M
Tensile strength 1103 1379 1310 1172 1138 1034 945
Yield strength 793 1275 1207 1138 1103 896 765
Elongation, % in 2''% 5 9 9 10 11 12 17
Rockwell hardness 35 45 43 38 37 33 31
