SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil
SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil
SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil
SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil
SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil
SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil
Specifications
Brand Name :
Daway
Model Number :
632, UNS S15700, PH15-7Mo
Certification :
SGS
Place of Origin :
China
MOQ :
500 kgs
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 tons per month
Delivery Time :
15 days after receipt 30% of value
Packaging Details :
Seaworthy
Type :
Semi-austenitic precipitation-hardening stainless steel
PH grade :
632, UNS S15700, PH15-7Mo
Product :
PH15-7Mo stainless steel sheet and strip
Size :
0.1~10.0X420mm
Delivery state :
Condition A, C
Specification :
ASTM A693, AMS 5520
Description

SUS632 Cold Rolled Stainless Steel Strip PH15-7Mo Stainless Steel Coil

Precipitation hardening stainless steel SUS632, PH15-7Mo

with high strength and hardness, good corrosion resistance, and satisfactory formability.

PH15-7Mo stainless alloy is particularly beneficial for a wide range of applications that

include retaining rings, springs, diaphragms, aircraft bulkheads, welded and brazed honeycomb

paneling and other aircraft components requiring high strength at elevated temperatures.

Chemical composition % weight

C Si Mn P S Cr Ni Mo Al
0.09 max. 1.00 max. 1.00 max. 0.040 max. 0.040 max. 14.00~16.00 6.50~7.75 2.00~3.00 0.75~1.50

Heat treatment

PH 15-7Mo Stainless Steel requires three essential steps in heat treating:

1) austenite conditioning,

2) cooling to transform the austenite to martensite

and 3) precipitation hardening.


The material normally is supplied from the mill in Condition A.

After fabrication, an austenite conditioning treatment is followed by a transformation treatment to

either Condition T or Condition R 100. Then the material is precipitation
hardened to either Condition TH 1050 or Condition RH 950 to develop fully useable properties.
To obtain the highest mechanical properties in this alloy, Condition A material is transformed to

martensite at the mill by cold reduction to Condition C.

After fabrication by the user, hardening to Condition CH 900 is accomplished with a single low-temperature heat treatment.

Specifications

AMS 5520 Sheet, Strip and Plate
ASTM A 693 Plate, Sheet and Strip (Listed as Grade 632-UNS S15700)
