Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Specifications
Applicable Industries :
Energy & Mining
Showroom Location :
None
Condition :
New
Type :
Magnetic Separator, permanent magnet or electromagnetic
Production Capacity :
98%
Place of Origin :
Shandong, China
Brand Name :
GUOTE
Voltage :
220V/380V
Dimension(L*W*H) :
1900*735*935
Weight :
750 KG
Warranty :
1 Year
Marketing Type :
Ordinary Product
Machinery Test Report :
Not Available
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor
Key Selling Points :
Easy to Operate, self-discharging
Application :
iron removal
Belt Width :
500-2000mm
Keywords :
Iron separator
Machine type :
Beneficiation Equipment
Advantage :
self discharging
Cooling type :
oil cooled
Magnetic intencity :
nlt700gs
overband magnets Capacity :
as required
Packaging Details :
Containers or according to customer requirements
Port :
QINGDAO
Supply Ability :
500 Set/Sets per Month
Price :
$38,800.00/sets 1-4 sets
MOQ :
1 set
Description
Product Description
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Introduction
Guote RCYD Self-cleaning Permanent Magnetic Separators for belt conveyor is made up with permanent magnetic chip , iron-discharging belt, reducer, frame and roller etc. and can match with all kinds of conveyors.
It is used to eliminate the ferromagnetic material weighing from 0.1kg to 35kg .we adopt the computerized simulating and make it still work in the harsh environment for a long period.
Specification
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

Features:
1)High magnetic field intensity, usually used in occasions with plenty of iron.
2)The wholly sealed structure makes the separator water-proof, dust- proof and corrosion resisting.
3)Made of rare earth NdFeB
4)High gauss
5)Energy saving
6)Easy to install and convenient to use.
7)High efficiency and stable performance.
8)Good operational reliability and flexibility
Model
Belt width (mm)
Magnetic strength (MT)
Material thickness (mm)
Driving power (kw)
Belt speed (m/s)
RCYD-6
600
60
120
1.5
4.5
RCYD-8
800
70
200
2.2
RCYD-10
1000
70
250
3
RCYD-12
1200
70
300
4
RCYD-14
1400
70
350
4
RCYD-16
1600
70
400
5.5
RCYD-18
1800
72
450
5.5
RCYD-20
2000
72
500
7.5
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Packing and shipping
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Recommend Products
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

RCYB Iron Separator

Permanent Magnetic Type
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

RCYD Iron Separator

Permanent Magnetic Type
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

RCYF Pipeline Iron Separator

Permanent Magnetic Type
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

RCDB Iron Separator

Electromagnetic Type
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

RCDD Iron Separator

Electromagnetic Type
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

RCYZ Pipeline Iron Separator

Permanent Magnetic Type
Company Profile
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Basic Company Introduction
Weifang guote mining equipment Co.,Ltd. is located in Qingzhou Economic Development Zone, Weifang City, Shandong Province. It covers an area of 40000 square meters. It is a high-tech enterprise in Shandong Province. The company has passed ISO9001 quality system certification, environmental system certification, safety management system certification, EU CE certification and more than ten useful national invention patents.
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
About GUOTE
Guote Mining equipment has long been committed to the production of quartz sand, silicon powder, feldspar and oil field fracturing
sand special equipment, and provide non-metallic ore production line experiment, design, consulting and the whole line equipment supply;such as：quartz sand making processing line equipment;glass sand making processing line equipment ;quartz powder making machine;sand washing system;drum dryer machine;dewatering screen equipment;vibration screen;scrubber attrition machine;magnetic separator machine...etc...
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Certifications
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined
Customer Photos
Self Unloading Belt Permanent Magnetic Remove Iron Separator Superior and Streamlined

About customers：

Our products are very popular at home and abroad, exported to Japan, South Korea,Thailand, Pakistan, Bangladesh, South Africa, India, Indonesia, Brazil, Vietnam, Malaysia and more than a dozen other countries and regions.
