FREESEA Stainless Steel Deep Well Pump for Industrial and Home Use

About This Item

Super Large Head & Flow: Powerful flow of the deep well pump can achieve 24 GPM, and the head can reach 390ft. More convenient and efficient to use water. Heavy-duty thermoplastic impellers are designed to provide large flow and high lift.
Premium Filtration Mesh: The filtration mesh of a submersible pump is made of stainless steel to filter impurities. You can add a layer of gauze in front of the filtration inlet for a new drilled well with excessive granular sediment.
Excellent Performance: The submersible water well pump is designed with an external check valve, which can be mounted vertically and is suitable for home use. The hermetically sealed motor is thermally protected to prevent overheating.
Various Application: This submersible pump for a deep well is suitable for extraction from the deep wells for groundwater and uses in rivers, reservoirs, canals, and other water lifting works. They are primarily used in farmland, factories, railways, and mines.

Advantage

High-quality Material

Super Large Head & Flow

Premium Filtration Mesh

Excellent Performance

Why Choose Us

High-Quality Motor & Rotor
The built-in thermal protector will automatically stop the pump when abnormal conditions appear, such as a machine's overload. The fixed-rotor uses a steel strip with high silicon content, features high dimensional accuracy, and good surface quality.
Superior Details
The large pump output is easy to connect to a hose or rigid pipe. Sling hole used for wire rope, nylon rope. You can connect copper core wire and an electrical conductivity plug to the power supply.
Wide Application
Our deep well pump is ideal for the home's freshwater supply. It can also be mainly used in farmland irrigation and mountainous water supply and draining in cities, factories, railways, and mines.

Product Parameter

Specifications

Motor: 1.5HP /1.1KW
Voltage: 110V/60Hz
Max flow: 5.6 m ³/ h 92 L/min 24 GPM
Rated Flow: 3 m ³/ h 50 L/min 13.2 GPM
Max Head: 119 m / 390 ft
Rated Head: 73 m / 240 ft
Revolutions: 2850 rpm
Internal Thread Diameter: 2"
Phase: Single
Item Dimension: 39.5x4 in/100x10 cm
Material: 304 Stainless Steel
Pump Diameter: 4 in/10 cm
Cable: 40m / 131ft
Weight: 55 lbs
