Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Handheld Digital Multimeter Smart TRMS 6000 Count NCV LIve Wire Frequency
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
HABO
Model Number :
HT113C
Supply Ability :
10000 Unit/Units per Month
Packaging Details :
Standard Export Carton 50pcs per carton
MOQ :
200 Unit/Units
Price :
$10.00 - $11.50 / Units
Measuring Current Range :
10A
Measuring Voltage Range :
0~600V AC DC
Measuring Resistance Range :
600 ~60M
Measuring Capacitance Range :
60nF~60mF
Measuring Inductance Range :
N/A
Operating Temperature :
0~40
Dimensions :
151*75*48 mm
Frequency :
10Hz~10MHz
NCV & Live Wire Test :
Yes
Data hold & Max Data :
Yes
Color :
Black
Backlight & Flashlight :
Yes
Size :
151*75*48 mm
Description

HT113 series Digital Multimeter

New Generation of Multimeter

SMT Technology

Small Meter with most of the functions

Battery test, Live Wire Test, NCV, True RMS, Max Data Hold.

Manual Range / Auto Range

Work Flashlight Available

High quanlity high Accurancy with affortable price

Operate by 2 x 1.5V AAA batteries easy to get anywhere

Functions Range Accuracy
HT113C
DC Voltage 200mV/2V/20V/200V/600V
400mV/4V/40V/400V/600V
600mV/6V/60V/600V ±(0.5%+3)
AC Voltage 200V/600V
400mV/4V/40V/400V/600V
600mV/6V/60V/600V ±(1.0%+3)
DC Current 200mA
400uA/4000uA/40mA/400mA
600uA/6000uA/60mA/600mA ±(1.2%+3)
10A ±(2.0%+3)
AC Current 200mA
400uA/4000uA/40mA/400mA
600uA/6000uA/60mA/600mA ±(1.5%+3)
10A ±(2.0%+3)
Resistance 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(1.0%+3)
Capacitance 60nF/600nF/6μF/60μF/600μF/6mF/60mF ±(4.0%+5)
Frequency 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz ±(1.0%+3)
Duty 1%~99% ±(3.0%+3)
Display 6000 Counts
Auto/Manual Range Auto
Live Test Yes
NCV Yes
Diode Test Yes
Continuity Yes
Max Data Hold Yes
Data Hold Yes
True RMS Yes
Bandwidth 1kHz
Battery test (1.5/9V)
Low Battery indication Yes
Auto Power Off Yes
Backlight Yes
Worklight Yes
Power 2x1.5V AAA batteries
Weight 250g
Size 151 x 75 x 48mm
Safety Rating EN61010-2-030 EN61010-2-033 CAT III 600V
