High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
HABO
Model Number :
HT113C
Supply Ability :
10000 Unit/Units per Month
Packaging Details :
Standard Export Carton 40pcs per carton
MOQ :
80 Unit/Units
Price :
$10.00 - $11.50 / Units
name :
precision capacitance meter
Measuring Voltage Range :
0~600V AC DC
Measuring Resistance Range :
600 ~60M
Dimensions :
151*75*48 mm
Display :
Auto Range 6000 counts
Frequency :
10Hz~10MHz
Color :
Black
Size :
151*75*48 mm
Power :
2*1.5V AAA Battery
Description

HT113 series Digital Multimeter

New Generation of Multimeter

SMT Technology

Small Meter with most of the functions

Battery test, Live Wire Test, NCV, True RMS, Max Data Hold.

Manual Range / Auto Range

Work Flashlight Available

High quanlity high Accurancy with affortable price

Operate by 2 x 1.5V AAA batteries easy to get anywhere

Functions Range Accuracy
HT113C
DC Voltage 200mV/2V/20V/200V/600V
400mV/4V/40V/400V/600V
600mV/6V/60V/600V ±(0.5%+3)
AC Voltage 200V/600V
400mV/4V/40V/400V/600V
600mV/6V/60V/600V ±(1.0%+3)
DC Current 200mA
400uA/4000uA/40mA/400mA
600uA/6000uA/60mA/600mA ±(1.2%+3)
10A ±(2.0%+3)
AC Current 200mA
400uA/4000uA/40mA/400mA
600uA/6000uA/60mA/600mA ±(1.5%+3)
10A ±(2.0%+3)
Resistance 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(1.0%+3)
Capacitance 60nF/600nF/6μF/60μF/600μF/6mF/60mF ±(4.0%+5)
Frequency 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz ±(1.0%+3)
Duty 1%~99% ±(3.0%+3)
Display 6000 Counts
Auto/Manual Range Auto
Live Test Yes
NCV Yes
Diode Test Yes
Continuity Yes
Max Data Hold Yes
Data Hold Yes
True RMS Yes
Bandwidth 1kHz
Battery test (1.5/9V)
Low Battery indication Yes
Auto Power Off Yes
Backlight Yes
Worklight Yes
Power 2x1.5V AAA batteries
Weight 250g
Size 151 x 75 x 48mm
Safety Rating EN61010-2-030 EN61010-2-033 CAT III 600V

High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm

High Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mmHigh Accuracy Automatic Digital Multimeter / Pocket Digital Multimeter Size 151*75*48 mm

Contact us for more detail, special offer and sample.
