320KW 500pcs/Min Elastic Ear T Shape Diaper Manufacturing Machine
320KW 500pcs/Min Elastic Ear T Shape Diaper Manufacturing Machine
320KW 500pcs/Min Elastic Ear T Shape Diaper Manufacturing Machine
320KW 500pcs/Min Elastic Ear T Shape Diaper Manufacturing Machine
Specifications
Brand Name :
HAINA
Model Number :
HNJX-TK500
Certification :
CE/ISO
Place of Origin :
JINJIANG, CHINA
MOQ :
1SET
Price :
Negotiatable
Payment Terms :
T/T
Supply Ability :
70 Machines Per Year
Delivery Time :
5 Months After Receiving Deposit and Confirm Product Drawing
Packaging Details :
Seaworthy Packing
Condition :
New
Web guider :
BST
Glue applicator :
Nordson
Product size :
S/M/L/XL
Design speed :
500pcs/min
Working speed :
450pcs/min
PLC :
Mitsubishi
Description

Full Automatic Elastic Ear T Shape Diaper Manufacturing Machine

Technical Parameters

1: Model: JWC-LLK600-SV
2: Power Source: Three Phase: 380V 50Hz
3: Installation Power: 320KW(excluding glue applicators, air compressor, the final power shall be confirmed after completion)
4: Product Sizes Medium and large sizes (only changing crotch size instead of changing waist size)
5: Production Speed:450 PCS/min (Medium)
6: Qualification Rate≥ 97%(excluding glue applicators, wastes caused by splicing raw materials)
7: Overall Size(L× W× H): 38m× 12m× 4.5m(for reference)
8: Machine Process Direction (raw material TO products)right to left(facing machine)

Product Structure


1: Core layer structure: Big cotton core adopts alien continuous stripping to shape and small cotton core adopts direct buckle the forming. Big cotton core and small cotton core are pressed solid after wrapping by tissues.
2. Acquisition layer slitting adopts scraping. (Scraping length is controlled by servo motors. )
3. Top sheets are composed of side nonwovens with elastic and middle materials, compressed by embossing units.
4. Nonwoven sectioning units adopts motor sectioning mode.
5. Tightness of elastic is adjusted by double roller linear velocity controlled by frequency conversion.
6. Roll material and tube material are compatible for elastic feeding.
7. Cotton core cutting and final product cutting adopt side blade scraping.
8. Color calibration of former icon straight cut adding unit.
9. Waist combination adopts heat seal.
10. Detailed shape, structure, sizes of products is confirmed according to the finalized products by both parties.

Design speed 600pcs/min
Stable speed 450pcs/min
Machine System(For new machine)

Customized

Option A: Mitsubishi

Option B: Simens
Glue machine

Customized

Option A: Chinese glue machine(Cost-effective)

Option B: Nordson machine
Web guide

Customized

Option A: Chinese web guide

Option B: BST web guide(or other brand)
Passing rate ≥ 98% (Not include the glue applicator, Auto Splicing)
Electric wire 3×120mm2+1×50mm2+1×25mm2
Compressed Air supply 0.6-0.8Mpa
Working space 40m*12m*5m(L*W*H)
