0.8Mpa Diaper Production Machine
0.8Mpa Diaper Production Machine
Specifications
Brand Name :
HAINA
Model Number :
HNJX-LK300
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
6 Sets per 1 Month
Delivery Time :
180 Work Days
Packaging Details :
Packed by international standard, anti-rusty treated and wrapped film packing.
Design Speed :
300ppm
Stable Speed :
250ppm
Product Size :
XL/L/M/S
Product Weight Tolerance :
±5%
Wastage :
≤4.0%(Excluding Glue, Splice, Raw Jointer Defectives）
Efficiency :
≥85%
Installation :
335KW（glue Machine & Air Compressor Not Included）
Power Suppl :
380 /440V 、50/60Hz (3 Phases, 4 Lines, Ground-in)
Air Compressor :
0.6-0.8Mpa
Machine Sizes :
38m×8m×4.5m（Including Mill, Pulp & Stacker）
Description

Full Servo Automatic Control Adult Diaper Making Machine With Stacker

Main technical parameters:

Machine Full Servo Automatic Control Adult Diaper Making Machine With Stacker
Model HNJX-CK300
Products Adult Diaper
Products Structure and dimension see product drawing

Product Structure

(Normal Type)

 Dual Phobic nonwoven, Philic nonwoven,ADL,core(upper tissue+anatomic core&SAP mixed+direct core&SAP mixed+lower tissue),Laminated nonwoven,Pe film,Frontal tape, Side tape double pieces, Common waist elastic,Leak cuff elastic,Leg elastic
Design speed 300 pcs/min
Production speed 250 pcs/min(M Size)
Defective rate ≤3%
Efficiency ≥85%
Power Supply 3 Phase 380VAC, 50HZ (base on customer local power)
Total Weight Around 95T
Power ~400KW
Required Air Compressor 2m³/min,0.6-0.8Mpa
Dimension L~45m,W~10m,H~4m
Machine direction According to the customer requirements
Color As required

See Machine Running Video on Youtube

https://youtu.be/TCew9Q-TpXI

Lab Test:

Haina Machinery has its own professional lab room, for each machine, when debug the machine before customers come to trial, engineers will forward the finished diaper to lab personnel, they will test each index strictly according to standard data. Find out where need to improve, and finally finish the debugging very well.

0.8Mpa Diaper Production Machine

Haina Patents:

Haina Machinery is always forcusing on innovation, we have got many patents since foundation to now. Inventive patents: 9 items, Utility model patent: 42 items, Design patent: 2 items, Patents under application: 98 items.

In some special important structure, Haina has it own advanced technique patent, it makes the baby diaper better quality and looks more nice. Moreover, the machine's service life is more longer.

0.8Mpa Diaper Production Machine

Packing Way
Anti-rusty Treated and Wrapped Film Packing
Some Parts Will Use Carton Box or Wood Case

0.8Mpa Diaper Production Machine
