Specifications
Brand Name :
TOKEN
Model Number :
TBV-AS12/24
Certification :
CE;ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Price Reconsideration
Supply Ability :
2.2K pcs per month
Packaging Details :
Little Carton Size:34*23*21CM;240pcs/Carton ;Large Carton Size:48*37*26CM;480pcs/Carton
product name :
hall effect voltage sensor
Usage :
hall effect sensor
Theory :
Hall Sensor
Operating temperature :
_40℃~+85℃
Color :
Blue and black
Type :
voltage transducer
Description

Current Mode Hall Voltage Transducer DC AC Pulsed Voltage Measurement

TBV-AS12/24 series current mode voltage sensor is a device based on the principle of the hall effect, with a galvanic isolation between primary and secondary circuit, It provides accurate electronic measurement of DC,AC or pulsed voltage.

Electrical data(Ta=25℃±5℃)

Type

Parameter

TBV50

AS12/24

TBV100

AS12/24

TBV200

AS12/24

TBV300

AS12/24

TBV400

AS12/24

TBV500

AS12/24

Unit

Rated input(Vpn)		 50 100 200 300 400 500 V

Measure range(Vp)		 100 200 400 600 800 1000 V

Turns ratio(Np/Ns)

 3333:1000 T

Rated input(Ipn)		 3.0 mA

Rated output		 @Vp=±Vpn ±2±0.5% V

Supply voltage		 12±5% /24±5% V

Consumption current		 20+IpX(Np/Ns) mA

Zero voltage		 5±0.5% V

Offset voltage drift		 @ -40℃～+85℃ ≤±0.3 mV/℃

Linearity		 @Vp=0-±Vpn ≤0.2 %FS

Response time		 ≤40 μS

Bandwidth		 20～10000 HZ

Galvanic isolation		 @ 50HZ,AC,1min 2.5 KV

Applications

AC variable speed drives and servo motor drives

Static converters for DC motor drives

Variable speed drives

Power supplies for welding applications

Battery supplied applications

Uninterruptible Power Supplies (UPS)

Switched Mode Power Supplies(SMPS)

Mechanical dimension(for reference only)

Current Mode Hall Voltage Transducer DC AC Pulsed Voltage Measurement

Remarks:

1. All dimensions are in mm.

2. General tolerance ±1mm

Directions for use

When the currentwill be measured goes through a transmitter ,the voltage will be measured at the output end.

(Note: The false wiring may result in the damage of the transmitter).

Customs can adjust Output amplitude of the transmitter by needs.

Custom design in the different rated input current and the output voltage available.

Standards

  • UL94-V0.
  • EN60947-1:2004
  • IEC60950-1:2001
  • EN50178:1998
  • SJ 20790-2000

General date

Value Unit Symbol
Operating temperature -40 to +85 ºC TA
Storage temperature -40 to +125 ºC TS
Mass(approx) 43 g M
