HDMI Over Fiber Optic Video Transmission 1 Channel For HD Video Systems
HDMI Over Fiber Optic Video Transmission 1 Channel For HD Video Systems
Specifications
Brand Name :
HD
Model Number :
HD-HDMI-2010
Certification :
CE/RoHS/FC
Place of Origin :
CHINA
MOQ :
10 PCS
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
3-7working days after received deposit
Packaging Details :
Packed in carton
Product Name :
Fiber Optic Video Transmission for HD Video Systems 1-Channel HDMI Over Fiber
input :
HDMI
output: :
hdmi+audio (SPDIF + R/L )
Operating Temperature :
-10 C~+75 C
Storage Temperature :
-45 C~+85 C
Power adaptor :
AC 100-240V to DC 5V 2A
Description

Fiber Optic Video Transmission for HD Video Systems 1-Channel HDMI Over Fiber

Features

• Support the input/output of HDMI ,with 1-Channel HDMI LOOP output

• Comply with HDMI 1.3 standard

• Support Full HD up to 1920x1080@60Hz ,3D

• HDCP 1.2

• 10G SFP+ optical transceiver to support Real-time / no-delay transmission of high-definition uncompressed HDMI video signals , the pictures showing on screen is clear and stable .

• Built-in ESD protection circuitry , can effectively prevent electrostatic damage

• 4 LED indicators to monitor the working conditions exactly and easily

• UpnP , easy installation

Specifications

HDMI

Connector: Type A 19pins

HDMI input/output port channel : 1

HDMI LOOP output port channel : 1

Input video signal level: 0.5-1.0 Vp-p

Input DDC signal level: 5 Vp-p (TTL)

Support Video format :

1920x1080@60Hz 1920x1080@50Hz

1920x1080@30Hz 1920x1080@25Hz

1920x1080@24Hz

1080i@60Hz 1080i@50Hz

1280x720@60Hz 1280x720@50Hz

Audio

PASS : HDMI audio output directly

2.0CH : RCA stereo audio output

5.1CH : S/PDIF audio output

Fiber Optic

Number of Optical port : 1 x 10G SFP+

Connector : Simplex LC/PC

Transmission Distance: Multi-mode 550m Single-mode 0 – 10Km

Wavelength: Transmitter 1270/1330nm Receiver 1330/1270nm

Electrical & Mechanical

Power adaptor : AC 100-240V to DC 5V 2A

Power consumption : <5W

Shipping weight: 1.80Kg/pair

(include external power adaptors & package box)

Stand-alone power: DC JACK

Dimensions : 165 x 80 x 30 mm (L .W.H)

Environmental

Operating Temperature : -10 C~+75 C

Storage Temperature : -45 C~+85 C

Relative Humidity : 0%~95% (non-condensing)

MTBF : >100,000 hours

Typical application

HDMI Over Fiber Optic Video Transmission 1 Channel For HD Video Systems
