Bluetooth Portable android handheld 2D
barcode scanner for Data Collector
Product Introduction:
1: MJ-2877 wearable ring scanner enable operator to move package ,products and materials, helping to increase more efficiency, It is very comfortable to wear it in whole working day, with high performance laser scan engine, even poor printed barcode can be read.
2: The rugged rubber shell makes daily use reliable even in the roughest environments.
3: MJ-2877 wireless function allowing unparalleled freedom for movement in scanning,it can be avoid drop down and damage scanner when you wearing on the finger. Super Class2 Bluetooth technology and long range 2.4G antenna make you transfer data with 20M distance.
4: You never need add more headcount to finish more work equip with MJ-2877 wearable ring-style scanner.At the same time, we provide RS232 and USB version to connect PC and Electronic label shelf
5: MJ-2877 can connect with iOS and android smart phone easily.Special design Bluetooth protocol, you can scan barcode into tablet PC and smart phone directly without install any software, double push trigger button, you can display and hide soft keyboard in iOS.
6. Symcode MJ-2877 QR Code 2D Image Pocket Barcode Scanner is capable of reading most widely-used 1D and 2D barcode on paper labels or displayed on the screen of a mobile phone, retailers can accommodate customer who downoad mobile coupons, mobile loyalty cards and more.
7. Symcode MJ-2877 QR Code 2D Image Pocket Barcode Scanner support omni-directional scanning of all 1D and 2D bar codes including poor quality. Users can read barcode in any orientation without having to align the bar code with the scanner. This point-and-shoot capability improves the first-time read rates while resulting in a faster through put and less operator fatigue.
8. Symcode MJ-2877 QR Code 2D Image Pocket Barcode Scanner ruggedized construction design, outstanding reading performance and versatile features sets provides an ideal solution for retail, logistics, healthcare and industry applications.
9. Symcode MJ-2877 QR Code 2D Image Pocket Barcode Scanner ruggedized construction design, outstanding reading performance and versatile features sets provides an ideal solution for retail, logistics, healthcare and industry applications.
Type | 2D Bluetooth image barcode scanner |
Color Depth | 32-bit |
Operating indicators | 2 LED (blue/green) |
Operating keys | 1 key total, 1 scan & power key |
Barcode scanner Optical | Sensor: 752*480 Resolution: 3 mil Print Contrast Ratio: 30% Depth of Field: 6-30cm Supported Symbologies: 1D:Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, China post 25, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1 Databar, etc. 2D:PDF417 / QR code / Data Matrix / Aztec, Maxicode |
Communication | Bluetooth module 4.0 Communication Mode: SPP, HID Distance:10 meters (visual) |
Power | Battery: 3.7V 1000mA Li-ion Current Consumption: 30mA Operating Current :100mA |
Memory | 512KB |
Durability | Temperature in operation: 0 to 50 oC / 32 to 122 oF Temperature in storage: -10 to 50 oC / -4 to 140 oF Humidity in operation: 20 - 85% (non-condensing) Humidity in storage: 20 - 85% (non-condensing) |
Physical | Dimensions (w x h x d): 100mm x 46mm x 21mm Weight: 190g (include battery) |
