380V 50HZ 3 Phase Facial Tissue Box Packing Machine 65 Boxes/Min
380V 50HZ 3 Phase Facial Tissue Box Packing Machine 65 Boxes/Min
Specifications
Brand Name :
YouYuan
Model Number :
YY-100F
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
50 Sets Per Month
Delivery Time :
60 Days
Packaging Details :
Export Wooden Package
Stable Production Speed :
30-65 boxes/min
Control System :
Servo motor, Touch screen, PLC control, HMI
Equipped Glue Machine :
International Advanced
Different Packing Sizes Change :
Adjustment finished in 15-20mins
Description

YY-100F Automatic Tissue Paper Packing Machine 30-65boxes/Min Cube Tissue Box

Description

YY-100F Automatic Tissue Paper Packing Machine is developed for automatic cube boxing of facial tissue products. It can connect with facial tissue paper interfolder and automatic transfer unit as well as log saw cutting machine to make an automatic box packing facial tissue production line.

The stable production speed can reach 65 boxes/min; Different packing sizes can be finished, it only takes 10-20mins to change to another packing size. Servo paper feeding and PLC control. Equipped with international advanced glue machine(a nozzle of 0.3-0.36mm), the glue spread is little to save your production cost.

Technical Specification

YY-100F Automatic Facial Tissue Box Packing and Sealing Machine
Name Technical parameters
Carton basis weight 300-400g/㎡
Maximum packing specification L115mm×W115mm×H135mm
Packing speed 30-65boxes/min
Glue hot melting machine power 2.5KW
Main motor 3.7KW
Total power 6.2KW
Air pressure 0.5-0.8Mpa
Air consumption 120-160L/min
Power supply type 3phase, 4wire, 380V, 50HZ
Machine size L3250mm×W1650mm×H1800mm
Machine weight 2100KG
Machine noise ≤80Db
Main performance and features

1. Packing forms such as automatic feeding, box opening, boxing, batch No. printing, glue spreading, box sealing, etc. are adopted. Featured by compact and reasonable structure, simple operation and adjustment.

2. Servo/step motor, Touch screen, PLC control system and HMI make operation more clear and convenient. With high automation degree, the machine is more user-friendly.

3. Compact and reasonable structure, simple operation and adjustment.

4. Automatic photocell detection tracking system is adopted. No boxing is made if the bag is empty, so as to save packing materials to the utmost extent.

5. Easy to change to different sizes. Change of specifications does not need change of molds, but can be realized through adjustment.

6.Protection automatically for overloading.

7. Internationally advanced glue machine is equipped to save your production cost.

380V 50HZ 3 Phase Facial Tissue Box Packing Machine 65 Boxes/Min

380V 50HZ 3 Phase Facial Tissue Box Packing Machine 65 Boxes/Min

380V 50HZ 3 Phase Facial Tissue Box Packing Machine 65 Boxes/Min

FAQ

1. Why choose YouYuan as the box facial tissue paper packing machine supplier?

Because we are professional box facial tissue paper packing machine manufacturer with more than 15 years experience. And we have a dedicated team for your questions before sales and after sales process. We can give you a turn-key project solution for box facial tissue paper packing.

After Sale Services

Spare Parts

YouYuan provides around-the-clock parts support to keep your business moving.

  • 24/7 breakdown support
  • 2,600+ part numbers stocked in our warehouse
  • Immediate response for non-stock parts requests
  • Professional team members dedicated to supporting your parts needs

Installation

We're here to get you started on the right foot.

  • Complete installation and start-up support

  • Start-up and calibration support

  • Staff training
