(1) Jumbo roll size:Maxφ1500mm×1200mm (jumbo roll diameter×width);

(2)Jumbo roll material:18-26g/㎡single-ply hand towel paper(wet-strength),suitable for glue lamination; 36-52g/㎡single-ply wood-pulp paper；

(3) Jumbo roll core inside diameter:3” (φ76m)

(4)Floor standing wall plate with thickness of 30mm.

(5)Two unwinding stands, two wide and flat belts for each unwinding stand.

(6)Paper tension is controlled by independent motor frequency conversion, It is slightly adjustable on the touch screen.

(1)Transverse cutting size: 230±2mm(other sizes please order);

(2)Folded size: 76±2mm;

(3)Product sizes:230x230mm.

(4)Production speed: 600-800sheets/min/line for laminated hand towel; 800-1000sheets/min/line for common hand towel.

(5)Product folding finished very smooth and neat, no wrinkles.

(1)One set of steel to steel emboss. Steel emboss roller is made by Laser engraving(Buyer provides the emboss pattern and confirm with seller)

(2) Upper and lower structure, Wall plate thickness 55mm, Pneumatic cylinder pressure control, Equipped with limit device.

(3)Paper dust removal and lubrication by felt; Safety device;

(4)The steel roller diameter is 240mm, roller thickness 40mm, The roller material is high frequency processed by special 40CR round steel.

(1)Two sets of steel-to-rubber emboss for lamination hand towel, steel emboss rollers are made by Laser Engraving(buyer provides the emboss pattern and confirms with seller);

(2)The embossing rollers can be synchronized with paper feeding unit and folding unit to ensure stable paper tension.

(3)Cylinder lever pressure, Easy to do web threading, paper dust removal by felt.

(4)The glue application parts will automatically open while the machine stops or while paper breaking; The glue roller will automatically rotate to avoid glue drying.

(5)Automatic glue washing by Push button(finish in 2 mins);

(6)Bell alarming while the glue is not enough.

(7)The steel embossing roller diameter is 290mm, the roller thickness is 40mm, The roller material is high frequency processed by special 40CR round steel.

(8)Initiative rolling cleaning device for steel glue application roller, ensuring no paper sticking on the roller(Invention patent)

(9)Wall plate thickness 55mm.

(1)Vacuum suction type;

(2)Transverse fixed knives can go up and down independently by cylinder , ensuring cut off

(3)Transverse rotary knives angle is adjustable.

(4)Floor standing wall plate with thickness of 55mm.

(5)Paper spreading by adjustable Arc-shape rollers.

(1)Vacuum pump:22KW(Longtech brand); Paper feeding motors: 1.5KW*2; 0.75KW(left and right moving);

(2)Main motor:7.5KW, Glue lamination unit:11KW

(3)380V, 50HZ(buyer confirms while order)

(4)Air pressure:≥0.5Mpa.

(5)Main motor frequency speed regulation, independent electric cabinet with air ventilation and cooling function.

(6)Movable Emergency stop switch box.

(1)PLC: Delta brand; Inverters: Delta brand. Touch screen: Delta brand.

(2)Baking paint for metal, machine drive in yellow color, main machine in creamy-white color, safety cover in creamy-white color;

(3)Export packaging;

(4)Safeguarding: All driving and nipping parts have safe covers and danger signs.

(5)All driving rollers adopts expansion sleeve.
