Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor
Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor
Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor
Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor
Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor
Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor
Specifications
Brand Name :
HanWei
Model Number :
HW-DZJS-2000
Certification :
CE
Place of Origin :
Shenzhen. China
MOQ :
1 Set
Price :
USD / Set
Payment Terms :
T/T
Supply Ability :
2000 Sets / year
Delivery Time :
10 working days
Packaging Details :
Export Plywood Packing
Laser Power :
2000W
Handheld Laser Gun Weight :
0.7 Kg
Welding Materials :
Steel / Stainless Steel / Aluminium
Welding Thickness :
6mm Stainless steel Full Penetration
Welding Laser Beam Size :
0-5mm Adjustable
Cleaning Laser Beam Size :
0-50mm Adjustable
Wire Feeding Device :
Standard type : 0.8&1.0&1.2&1.6mm wire
Double Route Wire Feeder :
Option ( Same time double route feeding )
Description

2000W Fiber Handheld Single Motor Three-in-One Machine

Handheld Single Motor Three-in-One Machine Description:

The Handheld Single Motor Three-in-One Machine marks a remarkable advancement in portable multi-purpose apparatus. Powered by a solitary, high-capacity motor, this gadget amalgamates three vital functions: welding, slicing, and purging, all encased within a sleek and user-friendly handheld casing.
During the welding process, it meticulously regulates the electrical current and voltage to produce a steady arc, thereby facilitating firm and precise welds on a variety of steel, stainless steel, and aluminum materials. For slicing tasks, a concentrated high-strength beam penetrates diverse material thicknesses with adjustable velocity and depth, guaranteeing neat and productive cuts. In the purging operation, it sucks in cleansing agents or water and converts them into a potent adjustable high-pressure jet through a flexible-nozzle, effectively eradicating rust, grease, and impurities. This machine is highly adaptable and appropriate for numerous settings like workshops, building sites, and industrial upkeep, delivering excellent performance across all three fundamental functions.

Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor

Handheld Single Motor Three-in-One Machine Features:

  • Product Name: Fiber Laser Three-in-One Machine
  • Laser Power: 2000W
  • Handheld Laser Gun Weight: 0.7kg
  • Welding Laser Beam Size: 0-5mm Adjustable
  • Cleaning Laser Beam Size: 0-50mm Adjustable
  • Standard Focus length: 60 & 150mm standard Focus length adjustable
  • Laser Head Connection: QBH
  • Laser Beam Form: Line “一”
  • Machine Electric Consumption: 10Kw/h about
  • Welding Materials: Steel / Stainless Steel / Aluminum
  • Welding Thickness: 6mm Stainless steel Full Penetration
  • Welding Parameter Save: 30 kinds of different welding parameter save

The Handheld Single Motor Three-in-One Machine proves to be an ideal choice for metal manufacturing, machinery restoration, and surface treatment in workshops and factories. It harnesses a 2000W laser power with an approximate consumption of 10Kw/h, enabling it to weld steel, stainless steel, and aluminum, and even achieve full penetration on 6mm stainless steel. The laser beam exhibits a linear form and is connected via QBH, with a requirement for argon or nitrogen gas. The 0.7kg handheld laser apparatus is equipped with an adjustable standard focal length spanning from 60 to 150mm. Additionally, it offers adjustable laser beam sizes for welding and cutting, where the welding beam size can be adjusted from 0 to 5mm and the cleaning beam size from 0 to 50mm.

Handheld Single Motor Three-in-One Machine Technical Parameters:

Product Name

Handheld Single Motor Three-in-One Machine

Laser Power

2000W

Handheld Laser Gun Weight

0.7 KG

Adopt Laser Source

1064~1080nm Fiber laser source

Welding Laser Beam Size

0-5mm Adjustable

Cleaning Laser Beam Size

0-50mm Adjustable

Standard Focus length

60 & 150mm standard Focus length adjustable

Fiber Connector

QBH

Cleaning Beam Form

Line " 一 "

Wire Feeding Device

Standard type : 0.8&1.0&1.2&1.6mm wire

Double Route Wire Feeder

Option (Same time double route feeding)

Welding Parameter Save

30 kinds of different welding parameter save

Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor

Handheld Single Motor Three-in-One Machine Application Advantages:

The HanWei HW - DZJS - 2000 Handheld Single Oscillation Tri-functional Machine exhibits remarkable application superiority. Its highly convenient portability stems from its compact and lightweight configuration, making it apt for confined spaces and on-the-go operations. This augments operational flexibility without the necessity of elaborate equipment or a large workforce.

This device amalgamates welding, cutting, and cleaning capabilities. In the welding function, possessing 2000W of power, it can perform welding on steel, stainless steel, and aluminum, attaining full penetration for 6mm stainless steel. The welding beam, adjustable within the range of 0 - 5mm, can adapt to diverse welding requirements. Regarding the cutting function, the laser beam can slice through materials with adjustable cutting speed and depth. In the cleaning function, the 0 - 50mm adjustable beam is efficacious in cleansing a variety of surfaces and is applicable in automotive, household, and industrial equipment cleaning.

It is energy-conserving and cost-efficient. The single-motor design economizes energy, streamlines work processes, curtails both time and energy consumption. Its uncomplicated structure leads to reductions in manufacturing and maintenance expenditures. It is also user-friendly, as it demands no specialized training, is accessible to a wide range of users, and helps to minimize errors and training-related costs.

Handheld Single Motor Three-in-One Machine Packing:

  • One Handheld Laser Gun
  • A set of Connection Cables and Line
  • One Touch Screen Monitor
  • One Controller
  • One Safety Switch Clip
  • One Focus Lens for cleaning
  • Two Protective Lens
  • One 15v Power Supply
  • Seven kinds of nozzles
  • One Wire feeding device
  • One User Manual

Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor

Three-in-One Laser Welding Cutting And Cleaning Machine 2000W Handheld Single Motor

Shen Zhen HanWei Laser Enterprise and Feature:

Shenzhen Hanwei Laser Equipment Co., Ltd. is dedicated to equipping all integrators with top-notch welding technology globally. As a national high-tech and specialized new enterprise, it specializes in researching, developing, manufacturing, and marketing the comprehensive industrial chain of welding lasers, laser control systems, laser optical systems, and laser welding processes. The company's product portfolio encompasses nine major series of laser welding machines, such as AMB Spot Ring Spot Welding Machine, Blue Light Welding Machine, and their associated supporting products.

Hanwei Laser adheres to the business philosophy of "centering on R&D, guaranteed by technology, and supported by service" to serve B-end clients. It has a talented team with extensive expertise in laser welding and related fields. The products find wide applications in diverse industries like new energy batteries, automotive, electronics, and household appliances, demonstrating unique welding performance. Notably, the company has achieved remarkable technological breakthroughs. The AMB Spot Ring Spot + Blue Light Composite Swing Welding Machine is a world-first, resolving issues in welding highly reflective materials. Other models like the AMB Spot Ring Spot + Semiconductor Composite Welding Machine and the Semiconductor + Single Lamp Single Rod 600W Composite Laser Welding Machine have also effectively tackled specific welding challenges in the power battery sector.
