Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
Specifications
Brand Name :
Runtai
Model Number :
Tapping Screws
Certification :
ISO9001/TS16949
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
50000
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5ton/day
Delivery Time :
14-21 days
Packaging Details :
Poly bag+Cartoon Box+ Wooden Pallet
Products Name :
Stainless Steel Phillips Drive Hexagon Flanged Head Tapping Screws
Material :
Stainless Steel Brass Copper Aluminum Alloy Steel
Standard :
DIN,ANSI,JIS,ASTM,GB
Size :
M1-M30 for choose
Surface Treatment :
Zinc Plated, Nickel Plated, Zinc-Nickel Plated, Black Oxide
Port :
Shanghai
Description

Stainless Steel Phillips Drive Hexagon Flanged Head Tapping Screws Flanged Hex Head Pointed Screws

Products Description

18-8 stainless steel screws have good chemical resistance and may be mildly magnetic. They have a hex head for a secure grip with a wrench and a flange to reduce the risk of crushing thin metal. Screws penetrate 0.025" and thinner sheet metal. Length is measured from under the flange. Head height includes the flange. Phillips drive easily install while using it. Slotted drive is optional drive for choose.

Products Specification

Screw Size No. 10
Screw Size Decimal Equivalent 0.190"
Length 7/8"
Head
Width 0.313"
Height 0.151"
Flange Diameter 0.414"
Drive Style External Hex/Phillips/ Slotted
Drill Bit Size No. 21
Drill Bit Size Decimal Equivalent 0.159"
Maximum Drilling Thickness 0.025"
Approximate Threads per Inch 12
Thread Direction Right Hand
Threading Fully Threaded
Tapping Method Thread Forming
Tapping Screw Type A/AB
Head Type Hex
Hex Head Profile Standard
Tip Type Pointed
Shank Cross Section Round
Screw Features Flanged
System of Measurement Inch
For Use In Sheet Metal
RoHS Compliant

Note: Material, Size and Surface Treatment for choose.

More Products Pictures

Hexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed ScrewsHexagon Flanged Head Metal Tapping Screws , Flanged Hex Head Pointed Screws
