Grade 10.9 Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws
Grade 10.9 Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws
Grade 10.9 Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws
Grade 10.9 Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws
Grade 10.9 Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws
Grade 10.9 Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
Runtai
Model Number :
M16X80
Supply Ability :
5 Ton/days
Packaging Details :
PP bag+Carton box+ Wooden Pallet
MOQ :
50000
Price :
Negotiable
Certification :
ISO9001/TS16949
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
15-20 working days
Size :
M1-M30 for choose
Material :
steel,stainless steel,copper,iron...
Grade :
4.8, 8, 10.9,12.9...
Surface treatment :
ZP,Dacromet,HDG, heat treating,etc
standard :
DIN, ASME,JIS,BS,FR and GB
Products Name :
Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws
Description

Carbon Steel Zinc Plated M16 Socket Drive Flat Head Machine Screws Coutersunk Head Screws

Products Descriptions

Choose these screws for their adherence to strict military standards for material and construction. They're zinc plated to resist corrosion in wet environments. Screws are angled under the head to sit flush within countersunk holes. Length is measured from the top of the head.

Products Specifications

Thread Size M16
Thread Pitch 2 mm
Length 60 mm
Threading Fully Threaded
Head Diameter 30 mm
Head Height 7.5 mm
Countersink Angle 90°
Drive Style Hex
Drive Size 10 mm
Material Black-Oxide Alloy Steel
Fastener Strength Grade/Class Class 10.9
Hardness Rockwell C32
Tensile Strength 120,000 psi
Thread Type Metric
Thread Spacing Coarse
Thread Fit Class 6g
Thread Direction Right Hand
Head Type Flat
Flat Head Profile Standard
System of Measurement Metric
Specifications Met DIN 7991, ISO 10642
RoHS Compliant
