Stainless Steel Flat Head Hex Socket Drive Self Drilling Screws For Metal
Stainless Steel Flat Head Hex Socket Drive Self Drilling Screws For Metal
Stainless Steel Flat Head Hex Socket Drive Self Drilling Screws For Metal
Stainless Steel Flat Head Hex Socket Drive Self Drilling Screws For Metal
Specifications
Brand Name :
Runtai
Model Number :
Tapping Screws
Certification :
ISO9001/TS16949
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
50000
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5ton/day
Delivery Time :
14-21 days
Packaging Details :
Poly bag+Cartoon Box+ Wooden Pallet
Products Name :
Zinc Plated Steel Phillips Drive Flat Head Self-Drilling Tapping Screws
Material :
Stainless Steel Brass Copper Aluminum Alloy Steel
Standard :
DIN,ANSI,JIS,ASTM,GB
Size :
M1-M30 for choose
Surface Treatment :
Zinc Plated, Nickel Plated, Zinc-Nickel Plated, Black Oxide
Grade :
4.8 8.8 10.9 12.9 for choose
Description

Stainless Steel Flat Head Hex Socket Drive Self-Drilling Screws for Metal


Products Description

Made from 410 stainless steel, these screws are strong, wear resistant, and mildly chemical resistant. They're beveled under the head for use in countersunk holes. They save you time and effort by drilling their own holes and fastening in a single operation. Not for use with aluminum. Length is measured from the top of the head.


Products Specification

Material 410 Stainless Steel
Screw Size No. 10
Screw Size Decimal Equivalent 0.19"
Length 1 1/4"
Flat Head Profile Standard
Drill Tip
Type No. 3
Length 1/4"
Maximum Drilling Thickness 0.15"
Head
Diameter 0.362"
Height 0.116"
Drive Size No. 2
Drive Style Phillips
Approximate Threads per Inch 16
Thread Direction Right Hand
Threading Fully Threaded
Tapping Method Thread Forming
Tapping Screw Type BSD
Head Type Flat
Countersink Angle 82°
Tip Type Drilling
Shank Cross Section Round
System of Measurement Inch
For Use In Steel, Stainless Steel, Sheet Metal
RoHS Compliant

Note: Material, Size and Surface Treatment for choose. OEM and ODM Products is welcomed

FAQ

Q1. Are you a manufacturing company or trading company?

A1: Our company has 20 years of production experience in fasteners and related products.

Q2. How to ensure that every process's quality?

A2: During the production, each process will be checked by our QC department. And before packaging, we'll have a full inspection by optical screening machines to insure every product's quality. Meanwhile, we also have some other testing equipments such as spectrograph, metallurgical microscope, hydraulic universal test machine, torsion test machine, salt spray test machine, etc.

Q3. Can you provide the sample?

A3: Sure, we could offer the sample for free charge but the cost of freight is not included.

Q4. What is your payment method?

A4: 30% value of T/T in advance and other 70% balance before shippment. If the order is less than 1000USD, we suggest you pay 100% in advance to reduce the bank charge.
