Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole
Specifications
Brand Name :
SS
Place of Origin :
CHINA
MOQ :
1 rolls/roll
Price :
US $2.43-75.69 / Rolls
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 rolls/week
Delivery Time :
Shipped in 20 days after receiving the deposit payment
Packaging Details :
1.Firstly Wraping with water-proof kraft paper. 2.Then use the plastic cloth or air cushion film to wrap. 3.Lastly put on the wooden pallet or put in wooden cases(with plastic cloth).
grade :
304 ,316 ,316L
wire dia :
0.02-2.03mm
mesh hole :
1-635 mesh
application :
filter
certificated :
SGS
weave :
plain weave
color :
silver
feature :
anti-corrosion
Description

Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole

  • Material : AISI 304 ,316 , 316 L ,430 ,410 etc
  • Mesh Size : 1 mesh -2300 mesh
  • Woven style: Plain, Twill, Dutch Twill, Reverse Dutch, Five-Heddle
  • Roll Width : 0.914m , 1.0m , 1.22m , 1.524m , 2.0m etc
  • Roll Length : 30m , 50m,etc.
  • Special size and material can be customized

Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole

Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole

Performance:

1. excellent acid resistance

2. alkaline resistance

3. heat resistance

4. high tensile strength

5. good anti rust property

Specifications

Type
Mesh/Inch
Wire diameter
(inch)
OPen Area
Weight (LB) /100 Square Foot
Plain,Twill Wire Mesh
1 × 1-635 × 635
0.0008"-0.08"
25 to 84.6
2.53 to 41.1
Type
Mesh/Inch
Wire diameter
(inch)
Absolute Filtration Finess μm
Nominal Filtration Finess μm
Plain Dutch Weave Wire Mesh
8 × 85 - 80 × 400
0.014'' × 0.0126''- 0.0049'' × 0.0028''
318-340 to 43-48
250-255 to 35-40
Twill Duntch Weave Wire Mesh
20 × 250 - 500 × 3200
0.0098'' × 0.0079'' - 0.0015'' × 0.0010''
110-120 to 8-9
98-105 to 2-3

Application:

as screening and filtering materials in oil industry, chemical industry, electronics, grain, rubber and other industries.

Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole

Stainless Steel Wire Mesh
Mesh/inch Wire Diameter
(mm)		 Aperture
(mm)		 Mesh/inch Wire diameter
(mm)		 Aperture
(mm)
2mesh 1.80 10.90 60mesh 0.15 0.273
3mesh 1.60 6.866 70mesh 0.14 0.223
4mesh 1.20 5.15 80mesh 0.12 0.198
5mesh 0.91 4.17 90mesh 0.11 0.172
6mesh 0.80 3.433 100mesh 0.10 0.154
8mesh 0.60 2.575 120mesh 0.08 0.132
10mesh 0.55 1.990 140mesh 0.07 0.111
12mesh 0.50 1.616 150mesh 0.065 0.104
14mesh 0.45 1.362 160mesh 0.065 0.094
16mesh 0.40 1.188 180mesh 0.053 0.088
18mesh 0.35 1.060 200mesh 0.053 0.074
20mesh 0.30 0.970 250mesh 0.04 0.061
26mesh 0.28 0.696 300mesh 0.035 0.049
30mesh 0.25 0.596 325mesh 0.03 0.048
40mesh 0.21 0.425 350mesh 0.03 0.042
50mesh 0.19 0.318 400mesh 0.025 0.0385
Width of Stainless Steel Wire Mesh: 0.6m-8m

Metal Fine Plain Weave 316 Wire Mesh Filter Screen Stainless Steel With 1 - 635 Mesh Hole

Packaging Details:

1.Firstly Wraping with water-proof kraft paper.

2.Then use the plastic cloth or air cushion film to wrap.

3.Lastly put on the wooden pallet or put in wooden cases(with plastic cloth).

Delivery Detail:

Shipped in 20 days after receive the deposits
