32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale
Specifications
Brand Name :
SS
Place of Origin :
CHINA
MOQ :
10 pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 pcs/week
Delivery Time :
10-15days after confirming the order
Packaging Details :
Wooden pallets or iron pallets wrapped with water proof films or any other package required by customers which are suitable for international shipment.
Certification :
SGS
Price :
$2.00 - $20.00 / Square Meters
material :
hot-dipped galvanized
Bearing bar pitch :
20,25,30,32.5,34.3,40,50,60
Cross bar pitch :
40, 50, 60, 65, 76, 100, 101.6
Cross bar size :
5X5, 6X6, 8X8mm
application :
floor
Bearing bar thickness :
2.5mm-10mm
Length :
1m, 2m, 5.8m, 6m, etc
width :
900mm, 1000mm, etc
certificated :
SGS
Description

32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale

Galvanized steel Grating made by welding with flat steel and cross/round bars with certain distances.

Our Galvanized Steel Grating enjoy the feature of high strength, light structure, high bearing, convenience for loading and other properties. The hot dipped zinc coating gives the product excellent anti-corrosion.

1)Raw material :Low carbon steel, stainless steel, aluminum alloy

2)Types of Steel Grating:Plain/smooth type, I type ,Serrated/teeth type.

32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale

Specification

Matrial Low carbonsteel / Stainless steel
Grade CN: Q235, Q345 ; UK: 43A
Bearing bar size 20X5, 25X3, 25X4, 25X5, 30X3, 30X4, 30X5, 32X3, 32X5, 40X5, 50X4... 75X8, 100X8mm, etc
Bearing bar pitch 20,25,30,32.5,34.3,40,50,60,62,65mm
Bearing bar type plain, Serrated (tooth-like), I bar (I section), Serrated-I
Cross bar size 5X5, 6X6, 8X8mm (twisted bar)/5, 6, 8mm ( round bar)
Cross bar pitch 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm, etc.
panel size: 1000x1000mm, 1000x2000mm, 1000x3000mm, 1000x6000mm
Surface treatment Untreated, hot DIP galvanized, cold DIP galvanized, painted, powder coated, pickling, electrolytic polishing, or as customers’ requirement.

32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale

Most Popolar

NO. Bearing size(mm) Cross bar pitch(mm) Weight(kg/square meter)
G253/30/50

25x3

 50 25.7
G253/30/100 100 22.8
G255/30/50

25x5

 50 39
G255/30/100 100 36.2
G323/30/50

32x3

 50 31.3
G323/30/100 100 28.4
G325/30/50

32x5

 50 48.4
G325/30/100 100 45.5

Surface treatment: untreated(black), hot-dipped galvanized ,powder coated, electroplate,

painting or as per customers’ requirement.

32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale

Galvansed Steel Grating

It is steel bar according to a certain distance and cross arranged and welded into the middle of a square latice with an iron and steel products . It is mainly used on the industrial platform , flooring , drainge cover , well cover , oil platform , stair tread etc.

bearing bar

25/3mm , 25mm/4mm , 25mm/5mm , 30/3mm , 30/5mm,32/3mm,32/5mm ,

40/3mm............ 75/5mm,100/10mm
opening

30mm x 32mm , 30mm x 60mm, 30mm x 100mm , 38mm x 100mm ,

40mm x 100mm , 50mm x 50mm ,50mm x 100mm etc

surface treatment black , hot dip galvanized
type plain bar, serrated bar , I shape bar

32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale

Packaging and shipping of steel walkway grating

Steel grating ready to delivery. Stock place of our factory.

32 * 5 / 30*3 Steel Grate Mesh/mesh grate/galvanised steel grating/steel walkway grating/metal grates for sale

Pre-sale Service

1. We will try our best to find a lowest freight cost for customers reference.

2. We have full stock, and can deliver within short time. Many styles for you to choose.

3. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.

4. All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.

After you choose

1. We will count cheapest shipping cost and make invoice to you at once.

2. Check quality again, then send out to you at 1-2 working day after your payment,

3. Email you the tracking no, and help to chase the parcels until it arrive you.

After-sale service

1. We are very glad that customer give us some suggestion for price and products.

2. If any question, please contact with us freely by E-mail or Telephone.
