1.Marterial:High-tensile steel wire and Galvanized wire;
2.Knot Types:Hinge Knot and Fixed Knot;
3.Wire diameter:General main wire is 2.0-2.5mm,edge wire is 2.5-2.8mm;
4.Width of mesh opening:7.5cm,15cm,30cm;
5.Height of mesh opening:Not less than 5.0cm of any size;
6.Height of mesh:0.8m,0.9m,1.0m,1.1m,1.2m,1.5m;
7.Length of mesh:50m,100m.
1:the first data in type is the NO. of line wire;the second data is horizontal hole size(mm);the thrid data is the height of the fence(mm);the fourth data is the total length of each roll(mm)
2:Height of fence is from 0.8m up to 2.0m, length is 50m 100m or 200m per roll.
3:Surface treatment can be made with electro galvanized or hot-dip galvanized, hot-dip galvanized cheap horse fence panels is much more durable.
4:Special size can be customized.
Specification for Field Fence | |||||
No. | Specifications and Hole Sizes | Gross Weight (kg) | Top and Bottom Wire Dia.(mm) | Inner Wire Dia.(mm) | |
Type | Specifications(the incremental vertical hole sizes) | ||||
1 | 7/150/813/50 | 102+114+127+140+152+178 | 19.3 | 2.5 | 2 |
2 | 8/150/813/50 | 89(75)+89+102+114+127+140+152 | 20.8 | 2.5 | 2 |
3 | 8/150/902/50 | 89+102+114+127+140+152+178 | 21.6 | 2.5 | 2 |
4 | 8/150/1016/50 | 102+114+127+140+152+178+203 | 22.6 | 2.5 | 2 |
5 | 8/150/1143/50 | 114+127+140+152+178+203+229 | 23.6 | 2.5 | 2 |
6 | 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 23.9 | 2.5 | 2 |
7 | 9/150/1245/50 | 102+114+127+140+152+178+203+229 | 26 | 2.5 | 2 |
8 | 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203 | 27.3 | 2.5 | 2 |
9 | 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 28.4 | 2.5 | 2 |
10 | 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 30.8 | 2.5 | 2 |
Galvanized cheap grassland fence purpose
Mainly for grassland construction,can WeiJian grasslands and implements the fixed-point grazing,
columns grazing. Facilitate plans to use pasture resources, effectively improve the efficiency of
grassland utilization and grazing, prevent grassland degradation, protect the natural environment.
Also apply to agriculture,animal husbandry profession of establishing family set up border farms,
farmland field, forest nursery, afforestation, the barricading of tourist area and hunting area,
construction site isolation maintenance etc.
Advantage
- Designed to withstand stock pressure in specific grazing applications
- Standard galvanized coating on all wires
- Available in different heights, lengths and picket spacings to suit a variety of grazing applications
- Advanced hinged joint construction - allows the fence to flex under load and then bounce back to its former position
- Suited to less demanding stock conditions and less corrosive environments
1)In Nude,which is the most popular packing ways as it could load bigger quantities,then lower unit price.
2) Plastic Film, uniform and good integration.
3)Wooden Pallet,save time and efforts,more convenient to load and discharge.
