Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer
Specifications
Brand Name :
SS
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1m2
Price :
US $3-5 / Square Meters
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000m2/week
Delivery Time :
Shipped in 2 days after payment
Packaging Details :
Plain Weave 40 60 80 100 150 200 Mesh N4 N6 Corrosion Resisting Pure Nickel Wire Mesh 1.Inside use carton pipe for support+wire mesh layer+water proof paper. 2.Outside use plastic wooden bags +wooden case/carton pipes/wooden pallets. 3.Also we can as per y
material :
FeCrAl wire
grade :
100% pure
used :
filter
wire dia :
0.010 to 1.20mm
width :
1m
length :
30m
feature :
Acid resistance
roll size :
1m*30m/roll
Description

iron chromium aluminum FeCrAl woven wire mesh screen/Cr20Ni80 FeCrAl woven wire mesh for electric cigarette atomizer

1.Material:Cr20Ni80, Cr15Ni60,Cr20Ni35, Cr20Ni30.

2.characteristics:

characteristic has bears the acid and alkali,against leakage ability strongly,the easy curl,the cost low status.Widely uses in the battery profession,the manufacture nickel cadmium,the nickel battery,the carp iron electron battery.
Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer

FeCrAl Mesh Highest Working Temperature:

Alloy Temperature
Cr21Al4 1100oC
Cr21Al6 1250oC
Cr23Al5 1250oC
Cr25Al5 1250oC
Kanthal D 1200oC
Kanthal A-1 1350oC



poperties of FeCrAl Mesh:

  1. Excellent heat resistance
  2. Prevents oxidation and sulfur based corrosion
  3. Anti-carburization
  4. Large surface load bearing
  5. High strength and durable
  6. Low temperature coefficient of resistance

specification:

Mesh/Inch Wire Gauge SWG Aperture mm
3 14 6.27
4 16 4.27
5 18 3.86
6 18 3.86
8 20 2.26
10 20 1.63
20 30 0.95
30 34 0.61
40 36 0.44
50 38 0.36
60 40 0.30
80 42 0.21
100 44 0.172
120 44 0.13
150 46 0.108
160 46 0.097
180 47 0.09
200 47 0.077


Applications of FeCrAl Heating Mesh:
FeCrAl Mesh is primarily utilized as drying and heating devices in metallurgy, colliery, dying, food storage, hospital, high density factory, industrial electric furnace, household appliances, gas burners and infrared equipments and heaters.
For your diverse application requirements, our heating mesh in various sizes provide excellent performance to become your preferred product. Contact us to discover how we have become the pioneer industrial mesh vendor since 1984.

Item FeCrAl wire mesh
Components Fe Cr Al
Material 1Cr13Al4, 0Cr25Al5, 1Cr12Al4....
Weave type Plain/twill weave
Mesh count 2-200 mesh
Width 0.2m-2m ,can be customized
Length 1-30m/roll , can be customized

Max-working temperature:

1Cr13Al4 - 950° 1Cr21Al4 - 1100°
0Cr21Al6 - 1250° 0Cr23Al5 - 1250°
0Cr25Al5 - 1250°
Features

Heat resistance , Oxidation resistance.
Sulfur resistance. Permeability resistance.
Superior elongation. Non-magnetic.
Applications

Mainly used as the drying and heating equipment in metallurgy , dyeing, food factory ,and so on.
Usual used in the industry electric furnace , household appliances, gas burners and infrared device .
Stock and customized All are available
Sample Free

Iron Chromium Aluminum FeCrAl Cr20Ni80 FeCrAl Fine Woven Wire Mesh Sheets For Electric Cigarette Atomizer

Our Services

  • We are specialized in filter mesh since 1980s
  • We will keep update production process news for you during order.
  • We will notice you in time if have any problem in production,and solve out that together.
  • We will give you wonderful after sale service
