MachineU > China Products > Minerals & Metallurgy > Wire Mesh > Barbed Wire
concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence
concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence
Specifications
Brand Name :
SS
Place of Origin :
CHINA
MOQ :
1 tons/ton
Price :
US $300-600 / Tons
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 tons/ton per week
Delivery Time :
10-15days after confirming the order
Packaging Details :
Barbed wire packaging is Plastic inside and hessian outside or plastic inside and waving bag outside. 1)in nude 2)in iron axletree 3)in wood axletree;
material :
galvanized
type :
twist
wire dia :
12*14 Gauge
barbed distance :
7.5-15cm
weight :
8-25kgs/roll
certificated :
SGS
application :
used as barrier for lawn
barbed length :
10mm-65mm
sample :
free
name :
barbed wire
Description

concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence

barbed wire size:

  • Made of l line wire with 4 spikes, spaced at a distance of 70 mm - 120 mm.
  • Horizontal line wire diameter 2.8 mm.
  • Barb wire diameter 2.0 mm.
  • Number of spikes 4.
  • Packed in coils: 25-45 kg/coil, or 100 m, 500 m/coil.

concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence

PVC

barbed wire

 Wire Diameter Barbs’ distance Barb length
Before coating After coating

7.5cm - 15cm

1.5cm - 3cm
1.0mm - 3.5mm 1.4mm - 4.0mm
Bwg11 - Bwg20 Bwg8 - Bwg17
Swg11 - Swg20 Swg8 - Swg17
Other sizes can be made as request
GALVANIZED BARBED WIRE

Wire Diameter

(BWG)

 Length per KG

Barb distance

3”

Barb distance

4”

Barb distance

5”

Barb space

6”
12 x 12 6.0617 6.7590 7.2700 7.6376
12 x 14 7.3335 7.9051 8.3015 8.5741
12.5 x 12.5 6.9223 7.7190 8.3022 8.7221
12.5 x 14 8.1096 8.8140 9.2242 9.5620
13 x 13 7.9808 8.8990 9.5721 10.0553
13 x 14 8.8448 9.6899 10.2923 10.7146
13.5 x 14 9.6079 10.6134 11.4705 11.8553
14 x 14 10.4569 11.6590 12.5423 13.1752
14.5 x 14.5 11.9875 13.3671 14.3781 15.1034
15 x 15 13.8927 15.4942 16.6666 17.5070
15.5 x 15.5 15.3491 17.1144 18.4060 19.3386

concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence

Kinds Electro galvanized wire
Hot galvanized wire
PVC coated wire
Material low carbon steel wire
Packing 25-50kg/coil
Inner plastic and outer hessian cloth
Gauge Gauge SWG mm BWG mm In Metric System mm
8# 4.06 4.19 4.00
9# 3.66 3.76 -
10# 3.25 3.4 3.50
11# 2.95 3.05 3.00
12# 2.64 2.77 2.80
13# 2.34 2.41 2.50
14# 2.03 2.11 -
15# 1.83 1.83 1.80
16# 1.63 1.65 1.65
17# 1.42 1.47 1.40
18# 1.22 1.25 1.20
19# 1.02 1.07 1.00
20# 0.91 0.89 0.90
21# 0.81 0.813 0.80
22# 0.71 0.711 0.70

concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence

Galvanized barbed wire with double strand size:

  • Made of 2 twisted line wires with 4 spikes, spikes spaced at a distance of 75 mm - 100 mm.
  • Horizontal wire barbed wire diameter 2.5 mm/1.70 mm.
  • Spikes wire diameter 2.0 mm/1.50 mm.
  • Strength of horizontal line wire: min. 1150 N/mm2 .
  • Strength of barb wire: 700/900 N/mm2.
  • Stranded wire breaking load: min. 4230 N.
  • Packed in coils: 20-50 kg/coil or 50 m - 400 m/coil.
Type Wire Gauge (SWG) Barb Distance (cm) /td> Barb Length (cm)
Electric Galvanized Barbed Wire; Hot-dip zinc plating barbed wire 10# x 12# /td> 7.5-15 1.5-3
12# x 12#
12# x 14#
14# x 14#
14# x 16#
16# x 16#
16# x 18#
PVC coated barbed wire; PE barbed wire before coating after coating 7.5-15 1.5-3
1.0mm-3.5mm 1.4mm-4.0mm
BWG11#-20# BWG8#-17#
SWG11#-20# SWG8#-17#
PVC PE coating thickness: 0.4mm-0.6mm; different colors or length are available at customers request.

concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence

Barbed Wire Packing: waterproof paper inside and woven bag outside or according to customer’s request

concertina wire cost/where to buy razor wire/barbed wire razor wire/barbed wire price per foot/prison barb wire fence

1. Hot Sale Size: 1.57mm, 2.0mm

2. Port of Loading: Tianjin, China

3. MOQ: 1 ton

4. Delivery Time: Within 10-25 days

5. Payment Term: T/T, L/C, Western Union, D/P
