Nickel Alloy ASTM B463 UNS N08020 Alloy20 plate sheet coil strip hot cold rolled
Nickel Alloy ASTM B463 UNS N08020 Alloy20 plate sheet coil strip hot cold rolled
Nickel Alloy ASTM B463 UNS N08020 Alloy20 plate sheet coil strip hot cold rolled
Nickel Alloy ASTM B463 UNS N08020 Alloy20 plate sheet coil strip hot cold rolled
Specifications
Brand Name :
HT
Model Number :
ASTM B463 UNS N08020 Alloy20
Certification :
PED SGS ISO TUV
Place of Origin :
China
MOQ :
50kg
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 kg per month
Delivery Time :
30-35 work days
Packaging Details :
wooden case, wooden pallet
Product Type :
Plate Sheet Strip Coil
Name :
ASTM B463 UNS N08020 Alloy20
Length :
0-12m or as per your requirements
Width :
0-2500mm or as per your requirements
Thickness :
0.3-1200mm or as per your requirements
Description
Nickel Alloy ASTM B463 UNS N08020 Alloy20 plate sheet coil strip hot cold rolledNickel Alloy ASTM B463 UNS N08020 Alloy20 plate sheet coil strip hot cold rolled

Alloy 20 Sheet/Plates Specification

STANDARD UNS WERKSTOFF NR. AFNOR EN
Alloy 20 N08020 2.4660 Z2NCUD31-20AZ NiCr20CuMo


Dimensions : ASTM, ASME and API
Specifications : ASTM B 463 / ASME SB 463
Grade : Alloy 20 – UNS N08020
Size : 15NB to 150NB In
Thickness : 0.3 mm to 120mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.

Alloy UNS N08020 Sheet/Plates Chemical Composition

Alloy 20 Ni C Mo Mn Si Fe P S Cr Nb Cu
32 – 38 0.02 max 2 – 3 1 – 2 0.7 max Bal 0.02 max 0.005 max 19 – 21 0.1 – 0.3 3 – 4

Alloy WERKSTOFF NR. 2.4660 Sheet/Plates Mechanical Properties

Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
8.1 g/cm3 1443 °C (2430 °F) Psi – 35000 , MPa – 241 Psi – 80000 , MPa – 551 30 %
