Tee Cross Stud End Duplex Steel Pipe Fittings ASTM SA815 WPS31803 WPS32205
Tee Cross Stud End Duplex Steel Pipe Fittings ASTM SA815 WPS31803 WPS32205
Tee Cross Stud End Duplex Steel Pipe Fittings ASTM SA815 WPS31803 WPS32205
Tee Cross Stud End Duplex Steel Pipe Fittings ASTM SA815 WPS31803 WPS32205
Specifications
Brand Name :
HT
Model Number :
ASTM SA815 WPS31803 WPS32205 45 DEG 90 DEG LR EBLOW TEE CROSS STUD END
Certification :
PED SGS ISO TUV
Place of Origin :
China
MOQ :
100piece
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 PIECE MONTH
Delivery Time :
15-20
Packaging Details :
WOODEN CASE
Material :
WPS31803 WPS32205
Name :
LR EBLOW TEE CROSS STUD END
Packing :
wooden case
Delivery time :
15-20
Description

A 815 / SA 815

Standard Specification For Wrought Ferritic, Ferritic/Austenitic, and Martensitic Stainless Steel Piping Fittings

1.1 This specification covers two general classes, WP and CR, of wrought ferritic, ferritic/austenitic, and martensitic stainless steel fittings of seamless and welded construction covered by the latest revision of ANSI B16.9, ANSI B16.11, ANSI B16.28, MSS Standard Practice SP-79, and MSS Standard Practice SP-43. Fittings differing from these standards may be furnished in accordance with Supplementary Requirement S8.

1. Duplex Steel S31803 BW pipe fittings
Duplex Steel S31803 180 Deg bend, Duplex Equal Tee, S32205 Duplex Alloy Reducer, Supplier of Duplex Steel S32205 45 degree Elbow, Duplex 1.5d Bend, ASTM A815 UNS S32205 Duplex Steel 90 degree Elbow Exporters and Suppliers in China.
UNS S31803 Duplex End Cap, Duplex 5d Bend, Duplex Steel 2205 Short Radius Elbow Supplier, Duplex Steel S31803 Pipe Fittings, ANSI B16.9 Duplex Steel S32205 Welded Buttweld Fittings, Duplex Steel WERKSTOFF NR. 1.4462 Cross Exporter in China.

2. S31803 Pipe Fittings Specifications

Duplex Steel S31803 / S32205 Pipe Fittings Specifications
Specifications:ASTM A815 / ASME SA815
Size:Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Standards:ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Thickness:5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75
Type:Seamless / Welded / Fabricated

3. Duplex UNS S31803 Forged Fittings

Duplex Stainless Steel UNS S31803 End CapDuplex Steel UNS S31803 3000 (3m) Bspp Fittings
Duplex Stainless Steel S31803 OutletSA 182 S31803 Round Head Plug
Duplex Stainless Steel S31803 CouplingDuplex S31803 3000 (3m) Fittings
Duplex Stainless Steel S31803 3000 (3m) Bspt FittingsDuplex Stainless Steel UNS S31803 6000 (6m) Bspt Fittings
Duplex Stainless Steel S31803 45° ElbowDuplex UNS S31803 A182 Buttweld Outlet
SA 182 S31803 90° ElbowDuplex UNS S31803 A182 3000 (3m) Npt Fittings
SA 182 UNS S31803 Hex Head PlugDuplex Steel S31803 Nipple
Duplex Stainless Steel S31803 Threaded Outlet (Npt)Duplex UNS S31803 Equal Cross
Duplex Steel S31803 6000 (6m) FittingsSA 182 UNS S31803 Elbow
Duplex S31803 CrossUNS S31803 DSS 6000 (6m) Sw Fittings
Duplex Stainless Steel S31803 TeeDuplex Steel UNS S31803 Square Head Plug
Duplex Steel UNS S31803 UnionDuplex UNS S31803 A182 Hex Nipple
Duplex Stainless Steel S31803 6000 (6m) Npt FittingsDuplex Stainless Steel S31803 Pipe Nipple
Duplex Steel S31803 Socketweld OutletSA 182 UNS S31803 Equal Tee
UNS S31803 DSS 3000 (3m) Sw FittingsSA 182 S31803 Full Coupling
Duplex Stainless Steel UNS S31803 Half CouplingDuplex Stainless Steel S31803 Plug
SA 182 S31803 Reducing TeeDuplex Stainless Steel UNS S31803 Street Elbow



4. About Duplex Steel S31803
Duplex Steel S31803 / S32205 Pipe Fittings Chemical Composition

S31803 / S32205CNPSiMnMoFeCrSNi
1.00.030.022.03.0 – 3.522.0 – 23.00.034.5 – 6.50.14 – 0.2Bal


Duplex Steel S31803 / S32205 Buttweld Fittings Mechanical Properties

S31803/ S32205DensityMelting PointYield Strength (0.2%Offset)Tensile StrengthElongation
7.8 g/cm31350 °C (2460 °F)Psi – 80000 , MPa – 550Psi – 116000 , MPa – 80015 %


Equivalent Grades for S31803 / S32205 Duplex Steel Pipe Fitting

STANDARDUNSWERKSTOFF NR.
Duplex Steel S31803S318031.4462
Duplex S32205S322051.4462


Duplex Steel S31803 / S32205 Buttweld Pipe Fittings Application Industries
Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry
