316L Duplex Stainless Steel Flanges Ring Forging Disc Customized Austenitic Structure
316L Duplex Stainless Steel Flanges Ring Forging Disc Customized Austenitic Structure
316L Duplex Stainless Steel Flanges Ring Forging Disc Customized Austenitic Structure
316L Duplex Stainless Steel Flanges Ring Forging Disc Customized Austenitic Structure
Specifications
Brand Name :
HT
Model Number :
stainless steel 316L ring forging disc customized products as per drawing
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 pcs
Price :
USD 1000/piece
Payment Terms :
L/C,T/T, Western Union
Supply Ability :
1000 pcs per month
Delivery Time :
30-35 work days
Packaging Details :
wooden case, wooden pallet
Product Type :
Flange, Disc, Foring, Shaft Sleeves
Name :
stainless steel 316L ring forging disc customized products as per drawing
Size :
1/2"-60"
Class :
150#, 300#, 400#, 600#, 900#, 1500#, 2500#
Surface :
oil rusted, yellow
Material :
Nickel alloy/stainless steel/duplex stainless
Description

stainless steel 316L ring forging disc customized products as per drawing

1. Grade 316L, the low carbon version of 316 and is immune from sensitisation (grain boundary carbide precipitation). Thus it is extensively used in heavy gauge welded components (over about 6mm). There is commonly no appreciable price difference between 316 and 316L stainless steel.

The austenitic structure also gives these grades excellent toughness, even down to cryogenic temperatures.

Compared to chromium-nickel austenitic stainless steels, 316L stainless steel offers higher creep, stress to rupture and tensile strength at elevated temperatures.

Composition

Table 1. Composition ranges for 316L stainless steels.

Grade C Mn Si P S Cr Mo Ni N
316L Min - - - - - 16.0 2.00 10.0 -
Max 0.03 2.0 0.75 0.045 0.03 18.0 3.00 14.0 0.10

Mechanical Properties

Table 2. Mechanical properties of 316L stainless steels.

Grade Tensile Str (MPa) min Yield Str 0.2% Proof (MPa) min Elong (% in 50 mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
316L 485 170 40 95 217

Physical Properties

Table 3. Typical physical properties for 316 grade stainless steels.

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Co-eff of Thermal Expansion (µm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100 °C (J/kg.K) Elec Resistivity (nΩ.m)
0-100 °C 0-315 °C 0-538 °C At 100 °C At 500 °C
316/L/H 8000 193 15.9 16.2 17.5 16.3 21.5 500 740

2. 316L forged ring specification

Materials

Stainless steel

Alloy steel

Carbon steel

Duplex stainless steel

Nickel alloy steel
Product:

Ring of Forging
Process:

forging equipments or rolling, forged or rolled
Application: bearing, machinery, oilfield, equipments
Size: 1/2"-72", 1/2"-160" and Customized
Standard: ANIS,DIN,ASTM,EN,BS,NF,JIS,ISO
Marking: As per the clients’ request

3. Forged Ring Processing

We take our commitment to our customers seriously. As an ISO 9001:2015 certified manufacturer, HT pipe inspects 100% of our rings to ensure conformance and performs testing per customer specific requirements. All non-destructive testing is performed in-house by our Level III technicians.

  • Heat treatment
  • Machining
  • Parting, splitting and segmenting
  • Shot blasting
  • Hardness testing
  • Ultrasonic inspection
  • Magnetic particle inspection
  • Mechanical analysis (charpy and tensile)
  • Chemical analysis
  • Positive material identification

For high-quality carbon steel rings, HT pipe is your solutions provider. We're available to answer questions about our carbon steel/stainless steel/nickel alloy steel/duplex stainless steel ring services.

4. 316L ring special customized goods photo for your reference:

316L Duplex Stainless Steel Flanges Ring Forging Disc Customized Austenitic Structure
