Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
Specifications
Brand Name :
HT
Model Number :
Alloy C-276 DIN2.4819 Hastelloy C276
Certification :
ISO, SGS, BV, TUV
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100000 sets per month
Delivery Time :
20-25 days
Packaging Details :
carton case+wooden case or wooden pallet or as per the clients' request
Product Name :
Alloy C-276 DIN2.4819 Hastelloy C276 bolt nut washer DIN933 DIN934 DIN125
Size :
M2-M64
Surface :
cold galvanized, PTFE, Zinc Nickel, Plain
Producing standard :
DIN, ASME
Type :
bolt nut washer thread rod
Package :
carton+wooden case
Material :
nickel alloy steel
Producing time :
15~20 days
Description

Alloy C-276 DIN2.4819 Hastelloy C276 bolt nut washer DIN933 DIN934 DIN125

1. About Hastelloy C276

Hastelloy Alloy C276 Bolts, Studs & Nuts Equivalent Grades

STANDARD WERKSTOFF NR. UNS GOST AFNOR JIS OR EN
Hastelloy C276 2.4819 N10276 ХН65МВУ - NW 0276 ЭП760 NiMo16Cr15W

Hastelloy C276 Bolts, Studs & Nuts Chemical Composition

Grade Ni Mo Cr Fe W Co Mn C v P S Si
Hastelloy C276 Bal 15 – 17 14.5 – 16.5 4 – 7 3 – 4.5 2.5 max 1.0 max 0.01 max 0.35 max 0.04 max 0.03 max 0.08 max

Hastelloy C276 Bolts, Studs & Nuts Mechanical & Physical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.89 g/cm33 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 Psi – 52,000 , MPa – 355 40%

Hastelloy Alloy C276 bolt nut washer stud Application Industries

•Off-Shore Oil Drilling Companies

•Power Generation

•Petrochemicals

•Gas Processing

•Specialty Chemicals

•Pharmaceuticals

•Pharmaceutical Equipment

•Chemical Equipment

•Sea Water Equipment

•Heat Exchangers

•Condensers

•Pulp and Paper Industry

2. Hastelloy C276 bolt nut washer stud specification

Material Size Length Specification

Hastelloy C276

Bolt nut washer stud

 M 02 to M 160

3 mm to

200 mm
  • DIN
  • ISO
  • JIS
  • GB
  • IS
  • BS
  • ASTM

Hastelloy Threads: METRIC, BSW, BSF, UNC, UNF or as required
Standard: DIN 933, DIN 931, ANSI, JIS standards
Hastelloy C276 bolt nut washer stud In Form of:
  • Hex
  • Square
  • Round
  • Threading as per Gauge Etc.
Head drive: Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Hastelloy C276 bolt nut washer stud Packing: IN BULK :canton/pallet, Small Boxes/carton/ pallet, or customer request
Hastelloy C276 bolt nut washer stud Test Certificate: Manufacturer Test Certificate as per EN 10204 / 3.1
Property Class:
  • For Bolts & Screws: A2-70, A2-80, A4-70, A4-80, F593C, F593D, F593G, F593H
  • For Nuts: A2-70, A2-80, A4-70, A4-80, F594C, F594D, F594G, F594H, A2-035, A4-040
  • For SHCS: F837B, F837C, F837E, F837
  • For Threaded Rods: A2-70, A2-80, A4-70, A4-80, F593C, F593D, F593G, F593H, B8, B8M CL1 & CL2
Production process M2-M24: Cold Forging, hot forging M24-M100,machining and CNC for Customized connecting element
Hastelloy Fasteners Grades: Hastelloy C22 Fasteners, Hastelloy C276 Fasteners, Hastelloy B2 Fasteners, Hastelloy B3 Fasteners, Hastelloy X Fasteners

3. HT pipe can offer best price on following Alloy C276 bolt nut washer stud screw

Hastelloy C276 Bolts Hastelloy C276 Round head square neck bolt Hastelloy C276 Washers
Hastelloy C276 Nuts Hastelloy C276 Hexagon socket head cap screw in full thread and half thread Hastelloy C276 Threaded Rod
Hastelloy C276 Screws Hastelloy C276 Hexagon wood screw Alloy C276 Bolts
Hastelloy C276 Studs Hastelloy C276 Hexagon socket button head screw Alloy C276 Nuts
Alloy C276 Studs Hastelloy C276 Hexagon socket button flange screw Alloy C276 Threaded Rod
Alloy C276 Washers Hastelloy C276 Hexagon socket counter sunk head cap screw in full thread and half thread ASTM B574 UNS N10276 Hastelloy C276 Fasteners
UNS N10276 Fasteners Hastelloy C276 square nuts Werkstoff Nr. 2.4819 fasteners
Hastelloy C276 Hex Nut Hastelloy C276 square weld nuts hastelloy C276 2.4819 UNS10276 fasteners
hastelloy C276 UNS N10276 2.4819 fasteners Hastelloy C276 hexagon weld nuts Hastelloy C276 special alloy hex nut,
hastelloy C276 u bolt Hastelloy C276 thick nylon nuts hastelloy C276 stud bolt
Hastelloy 2.4819 inside hexagonal bolt Hastelloy C276 hexagon flange nuts Hastelloy C276 half thread bolt
bearing hastelloy 2.4819 screws and bolts Hastelloy C276 threaded rods Hastelloy C276 Nuts Fastener
hastelloy C276 hex bolts Hastelloy C276 dowel screws UNS N10276 Hastelloy C276 half threaded hex bolt
Hastelloy C276 Flat Washer Hastelloy C276 dowel pin Hastelloy C276 Spring
Hastelloy C276 Countersunk Washer Hastelloy C276 Tooth Lock Washer Hastelloy C276 Hexagon head screw
Hastelloy C276 Hexagon head bolt Alloy C276 Hexagon Bolt Hastelloy Alloy C276 Hex Bolts

4. Hastelloy C276 bolt nut washer stud Test Certificates

We provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.

• EN 10204/3.1B,

• Raw Materials Certificate

• 100% Radiography Test Report

• Third Party Inspection Report, etc

ASME, ASTM and API Monel K-500 bolt nut washer stud Value Added Services

Material Testing:

We ensure that all our materials go through strict quality tests before dispatching them to our clients.

• Mechanical Testing Such as Tensile of Area

• Hardness Test

• Chemical Analysis – Spectro Analysis

• Positive Material Identification – PMI Testing

• Flattening Test

• Micro and MacroTest

• Pitting Resistance Test

• Flaring Test

• Intergranular Corrosion (IGC) Test

5. Hastelloy C276 bolt nut washer stud screw FAQ

Q:How does your factory do regarding quality control?

A:Quality is priority. we always attach great importance to quality controlling from the beginning to the end.

Mill Test Certificate is supplied with shipment. If needed, a Third Party Inspection is acceptable.
Q:May I have some samples before bulk order?
A:Yes, of course. samples are free but you have to pay the courier.
Q:Can we visit your Company?
A:Surely. Welcome to China and we will be honored to have a customer and friend.
Q:What is the payment terms?
A:T/T, L/C ,Western Union,etc.
Q:What's your delivery time?
A:For stocks, we can send the goods to loading port within 7 days after receiving your deposit.
For production period, it usually needs about 10days- 60days after receiving the deposit.
Q:Is it OK to mark my logo on your products?
A:Yes. OEM and ODM are available for us.

6. Hastelloy C276 bolt nut washer stud screw package

Alloy Hastelloy C276 Fasteners , Nickel Alloy Steel Bolt Nut Specialty Washers Fasteners
