Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Monel 400 Nickel Alloy Plate Hot / Cold Rolled High Strength ASTM B127 Standard
Specifications
Brand Name :
HT
Model Number :
Monel 400
Certification :
ISO,BV,SGS
Place of Origin :
China,USA,GERMANY,JAPAN
MOQ :
100kg
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100kg per month
Delivery Time :
3-50 days
Packaging Details :
steel frame or as per the clients' request
Type :
Plate, Sheet,Strip, Coil
Length :
0~12m or as per the client's requirements
Width :
0~2500mm or as per the client's requirements
Thickness :
0.3~1200mm or as per the client's requirements
Process :
Hot/Cold Rolled
Surface :
No.1 No.2D No.2B BA No.3 No.4 No.6 No.7
Packing :
Steel Frame, waterproof paper, wooden pallet, wooden case or as per the client's requirements
Origin :
USA, GERMANY,JAPAN,China
Description

ASTM B127 Alloy Monel 400 plate sheet strip with USA SMC ATI JAPAN YAKIN origin

1. MONEL 400 SHEETS & PLATES MANUFACTURER AND EXPORTER

HT PIPE are manufacturers, stockists and suppliers of Monel 400 Sheets & Plates across India that is fabricated from high quality raw materials. Monel 400 Sheets and Plates give great mechanical properties over an extensive variety of temperature and brilliant resistance to numerous corrosives, specifically hydroxides.

The Monel 400 Sheets & Plates manufactured by Speco Alloys Inc are known not only for its high quality but greater strength. It works in wide ranges of temperatures, and is made available to our clients in multiple forms and sizes according to their specifications and requirements.

2. MONEL 400 SHEETS & PLATES Specification

Standard ASTM B 127 / ASME SB 127
Size 15NB TO 150 NB IN
Grade Monel 400 (UNS No. N04400) Sheets & Plates, 2.4360
Type Sheet, Plates, Coils, Flat, Strips, Profile, Blank ,Circle, Ring etc.
Form Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Application Sulphuric Acid Production, Hydrochloric Acid Processes, Hydrofluoric & Fluorosilicic Acid Processes, Fatty Acid Production, Marine Industry and Shipbuilding,Propellers and Shafts, Fasteners, Oil and Gas Industry like Pumps, Valves, Crude Petroleum stills and process vessels, Heat Exchanger Plates.

3. MONEL 400 SHEETS & PLATES Chemical Composition

Element Min Max
Ni 63.0 70.0
Si -- 0.50
Fe -- 2.50
Cu Remainder Remainder
C -- 0.3
S -- 0.024
Mn -- 2.00

4. MONEL 400 SHEETS & PLATES Mechanical Properties

Product Form Tensile (ksi) .2% Yield (ksi) Elongation % Hardness (HRb)
Rod & Bar 75 to 90 25 to 50 60 to 35 60 to 80
Plate 70 to 85 28 to 50 50 to 35 60 to 76
Sheet 70 to 85 30 to 45 45 to 35 65 to 80

5. MONEL 400 SHEETS & PLATES Physical Properties

Density@ Room Temp 0.318 lb/in3
Elastic Modulus @ 70ºF (tension) 26.0 x 106psi
Specific Heat @ 70°F 0.102 Btu/lb/°F
Melting Point 2370°F to 2460°F
Thermal Conductivity @ 70°F 151 Btu • in/h/ft 2 /°F
Electrical Resistivity @ 70°F 0.511 μ Ω • m

6. MONEL 400 SHEETS & PLATES EXPORTS

Speco Alloys Inc exports MONEL 400 SHEETS & PLATES MANUFACTURER AND EXPORTER to Dubai, Sharjah, Abhdhabi, Oman, Qatar, Saudi Arabia, Kuwait, Iran, Iraq, Malaysia, Indonesia, Norway, Nigeria, Algeria, Egypt, Libya, Brazil, Angola, Guinea, Mozambique, Tanzania, Venezuela, Canada, Ecuador, Ghana, Vietnam, Trinidad And Tobago, Thailand, Korea, Taiwan, Australia, Italy, France, Spain, Russia, Germany & Azerbaijan countries.
