UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
Specifications
Brand Name :
HT
Model Number :
Stainles Steel 316Ti
Certification :
ISO SGS BV TUV
Place of Origin :
China
MOQ :
10KG
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000000Tons per Year
Delivery Time :
3-15 work days
Packaging Details :
Plywood case,pallet,woven bag,or other Seaworthy packed as customed
Product Name :
ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded pipes
Standard :
ASTM A312
Material :
Stainless Steel
Prodcut :
steel pipe tube
Type :
Seamless or welded
OD :
1/2"-48”
Thickness :
SCH 5-SCH XXS
End :
BE or PE
Description

ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded pipes

1. SS 316Ti Pipe Stock Size Range and Specifications

Grade Stainless Steel 316Ti / SS TP 316Ti / DIN 1.4571 Pipes / UNS S31635 Pipes
Standard ASTM / ASME SA213 / A249 / A269 / A312 / A358 CL. I to V ASTM A789 / A790
Steel EFW 316Ti Pipes 6" NB - 100" NB
Form Round, Square, Rectangular, Hydraulic Etc
Schedule SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length Single Random, Double Random & Cut Length. (Custom Sizes Available as per customers requirement)
Type Seamless / ERW / Welded / Fabricated / EFW
End Plain End, Beveled End, Treaded

2. About Stainless Steel 316Ti Pipe Tube

Standard SS 316TI
Werkstoff Nr. 1.4571
UNS S31635
JIS SUS 316Ti
AFNOR Z6CNDT17-12
BS 320S31
GOST 08Ch17N13M2T
EN X6CrNiMoTi17-12-2

316Ti Stainless Steel Pipes Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
316Ti min. – – – – – 16.0 2.00 10.0 –
max. 0.08 2.0 0.75 0.045 0.030 18.0 3.00 14.0 –

Stainless Steel 316Ti Pipe Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
316Ti 515 205 35 75 205

Stainless Steel 316Ti Pipes Physical Properties

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
316Ti 8000 193 17.2 17.8 18.4 16.2 21.5 500 720

4. Types of Stainless Steel Welded Pipes

Stainless Steel 316Ti Welded Pipe SS 316Ti Welded Pipe
316Ti SS Welded Pipe
SS 316Ti ERW Pipe
SS 316Ti EFW Pipe
Stainless Steel 316Ti ERW Pipe
Stainless Steel 316Ti EFW Pipe
316Ti Stainless Steel Welded Pipe
UNS S30400 Welded Pipe
WERKSTOFF NR. 1.4571 Welded Pipe
ASTM A312 TP 316Ti Stainless Steel Welded Pipes
Stainless Steel 316Ti Round Pipe SS 316Ti Round Pipe
316Ti SS Round Pipe
316Ti Stainless Steel Round Pipe
GOST 08Ch17N13M2T Round Pipe
UNS S31635 Round Pipe
SS UNS S31635 Round Pipe
ASTM A312 TP 316Ti Stainless Steel Round Pipes
Stainless Steel 316Ti Square Pipe SS 316Ti Square Pipe
316Ti SS Square Pipe
316Ti Stainless Steel Square Pipe
UNS S31635 Square Pipe
WERKSTOFF NR. 1.4571 Square Pipe
ASTM A312 TP 316Ti Stainless Steel Square Pipes

5. Extensive Inventory of 316Ti Stainless Steel Pipes for Sale in india at Best Price

Sr. No. Product Description Outside Diamter, OD (in mm) Wall Thickness, WT (in mm)
1 316Ti Stainless Steel Round Pipe 6mm – 630mm 0.5mm-30mm
2 316Ti Stainless Steel Square Pipe 12.7mm* 12.7mm to 300mm* 300mm 0.5mm-30mm
3 316Ti Stainless Steel Rectangular Pipe 10*20mm to 100*200mm 0.5mm-30mm
4 316Ti Stainless Steel Colour Coated Pipe 6mm to 630mm 0.5mm-30mm
5 316Ti Stainless Steel Ornamental Pipes 12.7mm to 76.2mm 0.5mm-2.0mm
6 316Ti Stainless Steel Electropolished Pipes 12.7mm to 250mm 0.5mm-30mm
7 316Ti Stainless Steel Slot Round Pipe 12.7mm to 76.2mm 0.5mm-2.0mm
8 316Ti Stainless Steel Triangle Pipe 16mm to 85mm 0.5mm-3.0mm
9 316Ti Stainless Steel Hexagonal Pipe 13mm to 85mm 0.5mm-2.0mm
10 316Ti Stainless Steel Handrail Pipe – 0.5mm-2.0mm
11 316Ti Stainless Steel U Shaped Pipe 20mm to 200mm 0.5mm-2.0mm
12 316Ti Thin-Wall Stainless Steel Pipe  22mm*0.7mm to 108mm*2.0mm 0.5mm-2.0mm
13 316Ti Inner/Outside Polished Stainless Steel Pipe 12.5mm to 203.2mm 1.0mm – 5mm
14 316Ti Stainless Steel Capillary Pipe 0.28mm to 10mm 0.08mm – 1.2mm
15 316Ti Stainless Steel Seamless Pipe 6mm to 430mm 0.8mm – 30mm

6. ASME SA358 SS 316Ti Pipes Popular Searches

ERW Stainless Steel 316Ti pipe, Fabricated Stainless Steel 316Ti Pipe , CDW Stainless Steel 316Ti Pipe, Stainless Steel 316Ti Cold Drawn Seamless Pipe, marine stainless steel 316Ti Piping, 10mm stainless steel 316Ti Pipe, 40mm stainless steel 316Ti Pipes, 12mm stainless steel 316Ti Pipe, stainless steel 316Ti pipe price, 4 inch 316Ti stainless steel pipe price, stainless steel 316Ti pipe price per foot, SS 316Ti pipe price, SS 316Ti pipe, SS 316Ti pipes, SS 316Ti pipes manufacturers, 3 inch stainless steel 316Ti pipe, 8 inch stainless steel 316Ti pipe, 1 inch 316Ti stainless steel pipe, 316Ti stainless steel pipe 2 inch, 316Ti stainless steel 2 inch pipe, 2.5 inch stainless steel 316Ti pipe, 12 inch stainless steel 316Ti pipe, stainless steel 316Ti pipe manufacturers, 316Ti stainless steel Pipe manufacturers, 316Ti stainless pipe manufacturers, 316Ti stainless steel pipe, SS 316Ti pipe, 316Ti SS pipe, 316Ti stainless steel welded pipe, 316Ti stainless steel welded pipes, large diameter 316Ti stainless steel pipe, large 316Ti stainless steel pipe, thick wall 316Ti stainless steel pipe, thin wall 316Ti stainless steel pipe, 316Ti stainless steel piping wall thickness

UNS S31635 AISI 316Ti Duplex Stainless Steel Pipe ASTM A312 Standard
