Cold Drawn 200 Nickel Alloy Pipe ASTM B161 N02200 Seamless Pipe Tube
Cold Drawn 200 Nickel Alloy Pipe ASTM B161 N02200 Seamless Pipe Tube
Cold Drawn 200 Nickel Alloy Pipe ASTM B161 N02200 Seamless Pipe Tube
Cold Drawn 200 Nickel Alloy Pipe ASTM B161 N02200 Seamless Pipe Tube
Specifications
Brand Name :
HT
Model Number :
Nickel 200 ASTM B161 N02200
Certification :
ISO TUV BV SGS,etc.
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram,etc
Supply Ability :
100000000tons per year
Delivery Time :
5~60days
Packaging Details :
Plywood case pallet,woven bag,etc.
Material :
Nickel 200 ASTM B161 N02200
Size Type :
1/2''~48''
Wall thickness :
SCH5~SCHXXS
Lenght :
As per your requirements
Type :
Seamless/Welded
End :
BE/PE
Standard :
ASME B36.10
Description

Factory price cold-drawn Nickel 200 ASTM B161 N02200 seamless pipe tube manufacturer

1. Nickel200 Pipe

UNS N02200 Welded Pipe Exporter, Suppliers of ASTM B161 Nickel 200 Seamless Pipes, GOST НП-2 Pipe, Nickel WERKSTOFF NR. 2.4066 Pipe Manufacturer in China.

200 Nickel Seamless Pipes, Alloy 200 Pipe, Nickel 200 Bush Hex Pipe, 200 Nickel Pipes, 200 Alloy Seamless Pipes, ASME SB622 Nickel Pipe Suppliers and Exporters in China.

Nickel 200 Seamless Pipe, Nickel 200 Welded Pipes, 200 Nickel Hollow Pipe, Nickel DIN NR. 2.4066 Pipes, Nickel 200 Hexagonal Pipe, ASME SB622 Welded Nickel Pipes, Nickel ® 200 Pipes, 200 Nickel Welded Pipe Manufacturer in China.

2. Nickel 200 Pipe Specifications

Specifications ASTM B 161 ASME SB 161 / ASTM B 622 ASME SB 622
Dimensions ASTM, ASME and API
Size 15″NB TO 150″NB IN
Specialized in Large Diameter Size
Type Seamless / ERW / Welded / Fabricated
Form Round, Hydraulic Etc
Length Single Random, Double Random & Cut Length.
End Plain End, Beveled End, Treaded

3. About Nickel 200

Nickel 200 Pipe Chemical Composition

Nickel 200 Ni C Mo Mn Si Fe P S Cu
99.0 min 0.15 max – 0.35 max 0.1 max 0.4 max – 0.01 max 0.25 max

Nickel 200 Pipe Mechanical Properties

Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
8.9 g/cm3 1446 °C (2635 °F) Psi – 21500 , MPa – 148 Psi – 67000 , MPa – 462 45 %

Equivalent Grades for 200 Nickel Pipe

STANDARD UNS WERKSTOFF NR. AFNOR EN JIS BS GOST
Nickel 200 N02200 2.4066 N-100M Ni 99.2 NW 2200 NA 11 НП-2

4. Nickel 200 Pipes Packaging
Nickel 200 Seamless Pipe may be furnished bare or coated and with capped ends. pipes up to 3” OD will be supplied in bundles. In order to prevent rust during sea shipment, bundles of Nickel 200 Seamless Pipe may be wrapped with polypropylene sheets, and secured with flat steel bands. Over 3” OD will be supplied loose.
