Hot Finished Incoloy Alloy 800ht Pipe , Seamless Welded Pipe ASTM B407B514 B515
Hot Finished Incoloy Alloy 800ht Pipe , Seamless Welded Pipe ASTM B407B514 B515
Hot Finished Incoloy Alloy 800ht Pipe , Seamless Welded Pipe ASTM B407B514 B515
Hot Finished Incoloy Alloy 800ht Pipe , Seamless Welded Pipe ASTM B407B514 B515
Hot Finished Incoloy Alloy 800ht Pipe , Seamless Welded Pipe ASTM B407B514 B515
Hot Finished Incoloy Alloy 800ht Pipe , Seamless Welded Pipe ASTM B407B514 B515
Specifications
Brand Name :
HT
Model Number :
N08811 Incoloy 800HT
Certification :
ISO SGS BV TUV
Place of Origin :
China
MOQ :
10KG
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000000Tons per Year
Delivery Time :
3-15 work days
Packaging Details :
Plywood case,pallet,woven bag,or other Seaworthy packed as customed
Product Name :
ASTM B407 B514 B515 Incoloy 800HT Alloy 800HT Seamless Welded Pipes Tubes
Standard :
ASTM B407 B514 B515
Material :
Incoloy steel
Prodcut :
steel pipe tube
Type :
Seamless or welded
OD :
1/2"-48”
Thickness :
SCH 5-SCH XXS
End :
BE or PE
Description


ASTM B407B514 B514 Incoloy 800HT Alloy 800HT Seamless Welded Pipes Tubes

1. INCOLOY 800HT Tube, INCOLOY 800HT Pipe, INCOLOY 800HT Tubing, INCOLOY 800HT Seamless Tube/ INCOLOY 800HT Welded Tube, INCOLOY 800HT Tubing Bends, Hot finished seamless INCOLOY 800HT tubing, Cold drawn seamless INCOLOY 800HT tubing, INCOLOY 800HT Electric resistance welded Pipe, INCOLOY 800HT Drawn over mandrel (DOM) supplier & distributor.

2. Specification Of Incoloy Alloy 800HT (UNS N08811) Pipe & Tube

SpecificationASTM B407, ASTM B163, ASTM B358, ASTM B515, ASME SB407, ASME SB163, ASME SB358, ASME SB 515,
DimensionsASTM, ASME and API
ScheduleSCH 5 , 10, 20 , 40 , STD , 60 , 80 , XS
LengthSingle Random, Double Random & Cut Length
FormRound, Square, Rectangular, Hydraulic Etc.
TypeSeamless / ERW / EFW / Welded / Fabricated / LSAW Pipes
Size15 NB to 150 NB IN


3. About Incoloy 800HT

Chemical Composition Of Incoloy Alloy 800HT (UNS N08811) Pipe & Tube

CMNPSSiCrNiMoCuCoCb+TaTiAlFeAl+TiGrain
.06 - .10 max----19.0 - 23.030.0 - 35.0----0.25 - 0.600.25 - 0.6039.5 min0.85 - 1.205 or coarser


Mechnaical Properties Of Incoloy Alloy 800/800H/800HT (UNS N08800/N08810/N08811) Pipe & Tube

Density7.94 g/cm3
Melting Point1385 °C (2525 °F)
Tensile StrengthPsi – 75,000 , MPa – 520
Yield Strength (0.2%Offset)Psi – 30,000 , MPa –205
Elongation30 %


4. Other Pipe Tube we have

TypeSeamless Pipe & TubeSAW/ ERW/ EFW Pipe & Tube
EndBE (Beveled End)PE (Plain End)
SizeOD 1/2" ~48"Thickness SCH5~SCHXXSLength As per client's requirement.
Manufacturing TechniqueHot rollingHot workCold rollingcold-drawn
Producing StandardASME B36.10ASME B36.19
Material GradeNickel AlloyASTM B474UNS N02200/Ni 200, UNS N02201 /Ni201,
UNS N04400/ Monel 400, UNS N06002 /Hastelloy X,
UNS N06022/ Hastelloy C22,
UNS N08825/ Incoloy 825, UNS N10276/ Hastelloy C276,
UNS N10665 /Hastelloy B2, UNS N10675/Hastelloy B3,
UNS N06600/Inconel 600, UNS N06601/ Inconel 601,
UNS N06625 /Inconel 625, UNS N08020 /Alloy 20
ASTM B161UNS N02200/Ni 200, UNS N02201 /Ni201
ASTM B163UNS N02200/Ni 200, UNS N02201 /Ni201,
UNS N06601/ Inconel 601 UNS N04400/ Monel 400,
UNS N06600/Inconel 600,
ASTM B165UNS N04400/ Monel 400
ASTM B407UNS N08800 /Incoloy 800, UNS N08810 /Incoloy 800H,
UNS N08811 /Incoloy 800HT
ASTM B729UNS N08020 /Alloy 20
ASTM B444UNS N06625 /Inconel 625 ,
ASTM B423UNS N08825/ Incoloy 825
ASTM B464UNS N08020 /Alloy 20
ASTM B622UNS N10665/Hastelloy B2, UNS N10675/Hastelloy B3,
UNS N06200/C2000, UNS N10276 /C276,
UNS N06002/ Hastelloy-X, UNS N08031/Alloy 31
Duplex SteelASTM A789S31803,S32205,S32750, S32760
ASTM A790S31803,S32205,S32750, S32760
Stainless SteelASTM A312TP304,TP304L,TP316,TP316L,316Ti, TP317, TP317L,
TP321, TP310S, TP347,S31254,N08367,N08926,N08904
ASTM A213TP304,TP304L,TP316,TP316L,316Ti TP317,TP317L,TP321,TP310S,TP347,S31254,
N08367, N08926,N08904
ASTM A269TP304,TP304L,TP316,TP316L,TP317,TP317L,TP321,
TP347, S31254,N08367,N08926
ASTM B676N08367
ASTM B677UNS N08925, UNS N08926
Alloy SteelASTM A333Grade 3, Grade 6,Grade 8,Grade 9
ASTM A335P5,P9,P11,P12,P22,P91,P92
Carbon SteelASTM A106 /A53GR.B
API 5LGR.B, X42, X46, X52, X56, X60, X65, X70 PSL1 & PSL2


5. Incoloy 800/ 800H/ 800HT Pipe Price List
800/ 800H/ 800HT Incoloy seamless pipes
US $2500-4100 / Ton (FOB Price)
seamless pipe astm B407 alloy 800/ 800H/ 800HT
US $800/ 800H/ 800HT-1200 / Ton (FOB Price)
Incoloy seamless pipe 800/ 800H/ 800HT
US $500-2000 / Ton (FOB Price)
ASTM B514 800/ 800H/ 800HT Incoloy welded pipe
US $850-2200 / Metric Ton (FOB Price)
sB407 800/ 800H/ 800HT seamless pipe
US $1.5-9 / Kilogram (FOB Price)
800/ 800H/ 800HT seamless pipe manufacturer
US $850-2200 / Metric Ton (FOB Price)
ASTM B514 Gr.800/ 800H/ 800HT Welded Pipe
US $500-1000 / Ton (FOB Price)
6. Incoloy 800/ 800H/ 800HT Seamless / Welded Pipes Application Industries
Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry
