Specifications
Brand Name :
HT
Model Number :
ASTM A333 Grade 3 Seamless and Welded Alloy Steel Pipe for Low-Temperature Service
Certification :
ISO SGS BV TUV
Place of Origin :
China
MOQ :
10KG
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000000Tons per Year
Delivery Time :
3-15 work days
Packaging Details :
Plywood case,pallet,woven bag,or other Seaworthy packed as customed
Product Name :
ASTM A333 Grade 3 Seamless and Welded Alloy Steel Pipe for Low-Temperature Service
Standard :
ASTM A333
Material :
Alloy Steel
Prodcut :
Steel Pipe Tube
Type :
Seamless or welded
OD :
1/2"-48”
Thickness :
SCH 5-SCH XXS
End :
BE or PE
Description

ASTM A333 Grade 3 Seamless and Welded Alloy Steel Pipe for Low-Temperature Service

1. ASTM A333 Grade 3 Seamless Pipe

ASTM A333 Grade 3 is the part of standard covers wall seamless and welded carbon and alloy steel pipe intended for use at low temperatures.

ASTM A333 Grade 3 alloy pipe shall be made by the seamless or welding process with the addition of no filler metal in the welding operation.

ASMT A333 Grade 3 seamless and welded pipes shall be treated to control their microstructure. Tensile tests, impact tests, hydrostatic tests, and nondestructive electric tests shall be made in accordance to specified requirements.

Seamless and Welded Steel Pipe size for Low-Temperature Service:

Outer Dimensions: 19.05mm – 114.3mm

Wall Thickness: 2.0mm – 14 mm

Length: max 16000mm


2. Application: Seamless and Welded Steel Pipe for Low-Temperature Service.

Steel grade: ASTM A333 Grade 3

3. Packing:

Bare packing/bundle packing/crate packing/wooden protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.
Inspection and Test: Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength, Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

Surface treatment: Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting.
Both ends of each crate will indicate the order no., heat no., dimensions, weight and bundles or as requested.

4. ASTM A333 Grade 3 Chemical Compositions(%)

Compositions Data
Carbon(max.) 0.19
Manganese 0.31-0.64
Phosphorus(max.) 0.025
Sulfur(max.) 0.025
Silicon …
Nickel 3.18-3.82
Chromium …
Other Elements …

5. Mechanical properties for ASTM A333 Grade 3 Alloy Steel

Properties Data
Yield strength(min) 450 Mpa
Tensile strength(min) 240 Mpa
Elongation(%, min) Y 30
Elongation(%, min) X 20

6. Strike Temperature Condition for ASTM A333 Grade 3

The lowest temperature for strike test
℉ ℃
-150 -100

7. Other ASTM Standards

A262 Practices for Detecting Susceptibility to Intergranular Attack in Austenitic Stainless Steels

A941 Terminology Relating to Steel, Stainless Steel, Related Alloys, and Ferroalloys

A1016/A1016M Specification for General Requirements for Ferritic Alloy Steel, Austenitic Alloy Steel, and Stainless Steel Tubes

E112 Test Methods for Determining Average Grain Size
