Seamless / Welded Ferritic Alloy Steel Pipe ASTM A335 P5 P9 P11 BE / PE End
Seamless / Welded Ferritic Alloy Steel Pipe ASTM A335 P5 P9 P11 BE / PE End
Specifications
Brand Name :
HT
Model Number :
Ferritic Alloy Steel Pipe ASTM A335 P5 P9 P11 P22 P91 Seamless Pipe
Certification :
ISO SGS BV TUV
Place of Origin :
China
MOQ :
10KG
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000000Tons per Year
Delivery Time :
3-15 work days
Packaging Details :
Plywood case,pallet,woven bag,or other Seaworthy packed as customed
Product Name :
Ferritic Alloy Steel Pipe ASTM A335 P5 P9 P11 P22 P91 Seamless Pipe
Standard :
ASTM A333
Material :
Alloy Steel
Prodcut :
Steel Pipe Tube
Type :
Seamless or welded
OD :
1/2"-48”
Thickness :
SCH 5-SCH XXS
End :
BE or PE
Description

Ferritic Alloy Steel Pipe ASTM A335 P5 P9 P11 P22 P91 Seamless Pipe

1. ASTM A335 / ASME SA335 P5, P9, P11, P22, P91 Seamless Alloy Steel Pipes Manufacturer, Exporter and Supplier Worldwide

ASTM A335 P5, P9, P11, P22, P91 Seamless Pipes, Tubes Specifications, Stock and Supply Range

Size Range : 1/2” NB to 36” NB

Alloy Steel Pipes Specifications : ASTM A/ASME SA 335 P1, P2, P5, P9, P11, P12, P22, P23, P91, and P92

Thickness Range: SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules, upto 12mm thk

Type : Seamless / ERW / Welded / Fabricated / CDW

Form: Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes

Length: Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths

End: Plain End, Beveled End, Treaded

End Protection: Plastic Caps

End Connections for Line Pipes: Plain, Bevel, Screwed, Threaded

Outside Coating: Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements

Inspection, Test Reports: Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports, India Boiler Regulations (IBR) Test Certificate

Packing: Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests

Specials: Sizes and Specifications other than above can be manufactured on request

2. ASTM A335 / ASME SA 335 P5, P9, P11, P22, P91 Seamless Pipes Chemical Composition :

Grade C Mn P S Si Cr Mo
P5 0.15max 0.30-0.60 0.025 0.025 0.50 max 4.00-6.00 0.45-0.65
P9 0.15 max 0.30-0.60 0.025 0.025 0.25-1.00 8.00-10.00 0.90-1.10
P11 0.05-0.15 0.30-0.60 0.025 0.025 0.50-1.00 1.00-1.50 0.44-0.65
P22 0.05-0.15 0.30-0.60 0.025 0.025 0.50 max 1.90-2.60 0.87-1.13
P91 0.08-0.12 0.30-0.60 0.02 0.01 0.20-0.50 8.00-9.50 0.85-1.05
V 0.18-0.25 N 0.03-0.07 Ni 0.40 max Al 0.02 max Cb 0.06-0.10 Ti 0.01 max Zr 0.01 max

3. ASTM A335 / ASME SA 335 P5, P9, P11, P22, P91 Seamless Pipes Mechanical Properties :

Grade Tensile strength(MPa) Yield strength(MPa) Elongation(%) Impact energy(J) Hardness
P11 ≥ 415 ≥ 205 ≥ 22 ≥ 35 ≤ 163HB
P12 ≥ 415 ≥ 220 ≥ 22 ≥ 35 ≤ 163HB
P22 ≥ 415 ≥ 205 ≥ 22 ≥ 35 ≤ 163HB
P5 ≥ 415 ≥ 205 ≥ 22 ≥ 35 ≤ 187HB
P91 585~760 ≥ 415 ≥ 20 ≥ 35 ≤ 250HB
P92 ≥ 620 ≥ 440 ≥ 20 ≥ 35 250HB

4. Tolerance for ASTM A335/ASME SA 335 P5, P9, P11, P22, P91 Seamless Pipes :

NPS OD Tolerance NPS WT Tolerance
1/8″ ≤ NPS ≤ 1 1/2″ +/- 0.4 1/8″ ≤ NPS ≤ 2 1/2″ , All T/D ratios. +20%, -12.5%
1 1/2 < NPS ≤ 4″ +/- 0.79 NPS ≥ 2 1/2″ , T/D ≤ 5% +22.5%, -12.5%
4″ < NPS ≤ 8″ +1.59, -0.79 NPS ≥ 2 1/2″ , T/D > 5% +15%, -12.5%
8″ < NPS ≤ 12″ +2.38, -0.79 (T= Specified Wall Thickness; D = Specified Outside Diameter)

5. ASTM A 335 Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High Temperature Service :

Trade Name Grade UNS # Pipe Forged / Bored Pipe *
1 1/4 Chrome P11 K11597 A335 / SA335 A369 / SA369
2 1/4 Chrome P22 K21590 A335 / SA335 A369 / SA369
5 Chrome P5 K41545 A335 / SA335 A369 / SA369
9 Chrome P9 S50400 A335 / SA335 A369 / SA369
P91 P91 K91560 A335 / SA335 A369 / SA369
P92 P92 K92460 A335 / SA335 A369 / SA369

Seamless / Welded Ferritic Alloy Steel Pipe ASTM A335 P5 P9 P11 BE / PE End
